Copper Buttweld Fittings are precision engineered pipe fittings that are used to join, redirect, reduce or terminate copper pipe systems. The fittings ensure a secure connection while offering a seamless flow within the piping system.
Kanchan Copper provide Copper Buttweld Elbows, Tees, Couplings, Reducers, End Caps, Stub Ends, U Bends and Y Bends for various piping needs and we are Copper Buttweld Fittings Manufacturer & Exporter in Mexico. Copper fittings are ideal for HVAC and refrigeration, medical gas, plumbing, industry and commercial piping.
Kanchan have various sizes, wall thicknesses, shapes and specifications of Copper Buttweld Fittings in Mexico to cater project needs. High dimensional accuracy, stable production, surface treatment and stable connection performance are our concerns.
Copper Buttweld Fittings
Copper Buttweld Fittings are used to join copper pipes to each other by butt welding. These fittings are suitable for copper brazing and joining by appropriate methods according to the application and requirement of the system.
Copper Buttweld Fittings in Mexico are provided to contractors, distributors, engineering firms, HVAC firms, plumbing suppliers and industrial projects that need and depend on reliable copper piping components.
Copper Buttweld Fittings Types
Kanchan Copper have a variety of Copper Buttweld Fittings to suit various piping systems such as changing direction, adding a branch, changing pipe sizes and closing the end of a pipe.
Copper Buttweld Elbows Fittings
Copper Buttweld Elbows are used to change the direction of copper piping systems. They come in various configurations and at varying bend angles depending on the needs of the piping job.
Copper elbows 45 degree and 90 degree are frequently employed for routing copper pipes in HVAC and refrigeration, plumbing and industrial applications.
Copper Buttweld Tees Fittings
Copper Buttweld Tees are fabricated to make a branch connection off a primary copper pipe. They can be supplied in either equal or reducing designs, depending on the pipe arrangement that is needed.
The copper tee is a typical fitting employed to branch off a piping system or to divide a system.
Copper Buttweld Coupling Fittings
Copper Buttweld Couplings are for straight-line joints between two copper pipes. They can be used for a longer pipe run or for connecting two pipe sections that are compatible.
They’re small enough to be used in a range of copper pipe installations where a straight connection is needed.
Copper Buttweld End Caps Fittings
Copper Buttweld End Caps are used to close or terminate the end of a copper pipe. They are used to seal lines in a piping system that are no longer in use or to close off a terminated pipeline.
Copper end caps can be installed in new installations, piping changes, maintenance and system additions.
Copper Buttweld Reducers Fittings
Copper Buttweld Reducers are used to connect copper pipes with different outside diameters. They are used to connect larger and smaller pipe sizes in a piping system.
Reducers can be used if a change in pipe size is necessary, but the alignment and small connection size is to be maintained.
Copper Buttweld Stub Ends Fittings
Copper Buttweld Stub Ends are stub ends for use in piping applications that need to be flange connected. They are designed to fit with an end connection option for the integration with an appropriate flange arrangement.
Stub ends may be helpful in a system where it is necessary to remove, inspect, maintain, or change a portion of pipe.
Copper U Bend Buttweld Fittings
Copper U Bend Buttweld Fittings are U-shaped fitting products, which are used to create a return bend in a copper pipe system.
They can be employed when the return path or routing is required to be compact for the piping layout. U bends are available for HVAC, refrigeration, heat-transfer and other special copper piping applications.
Copper Y Bend Buttweld Fittings
Copper Y Bend Buttweld Fittings are used for special piping installations that need a Y-shaped fitting.
They can be produced to the required size and project specifications for specific industrial and copper pipe jobs.
Copper Buttweld Fittings Specification
Copper Buttweld Fittings can be produced and supplied in various sizes, different wall thicknesses, materials and configurations depending on the type of fitting and their application. The material grade, dimensions, wall thickness and applicable standard can be selected according to the actual requirement of the piping system and customer requirements.
| Standard | ASTM B819, EN 1057, EN 13348, ASTM B88 |
|---|---|
| Size | 1/2″ to 24″ NB |
| Thickness | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
| Type | Welded |
| Schedule | SCH 10, SCH 20, SCH 30, SCH 40 |
| Grades | DHP Copper, C10100, C10200, C11000, C12000, C12200 |
| Application | HVAC & Refrigeration, Plumbing, Industrial Piping, Heat Exchangers, Cooling Systems, Engineering Applications |
Copper Buttweld Fittings Pressure Rating Schedule Chart
| NPS (Normal Size Of Steel Pipe) | 10S Sche | 40S Sche | 80S Sche | ||||||
|---|---|---|---|---|---|---|---|---|---|
| 90 Deg Elbow | 45 Deg Elbow | Equal Tee | 90 Deg Elbows | 45 Deg Elbows | Equal Tee | 90 Deg Elbow | 45 Deg Elbow | Equal Tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.1 | 0.1 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.2 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.4 | 0.23 | 0.68 |
| 40 | 0.3 | 0.17 | 0.68 | 0.4 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.5 | 0.25 | 0.85 | 0.7 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.4 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.2 | 1.08 | 3.31 | 2.97 | 1.5 | 4.45 |
| 90 | 1.7 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4 | 2 | 5.44 |
| 100 | 2.1 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.2 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.9 |
| 300 | 25.8 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Copper Elbow Buttweld Fittings size, dimension chart
| NPS For (Normal Size Of Pipe) | O.D. For (Outside Dai.) | BW 90 Deg Elbow | BW 45 Deg Elbow | BW Return 180 Deg Elbow | ||||
|---|---|---|---|---|---|---|---|---|
| BW (Long Radius) Elbow | BW (Short Radius) Elbow | BW (Long Radius) Elbow | BW (Short Radius) Elbow | |||||
| (In Inch) | (MM) | (inch) | Center-Face (Inches) | Center-Face (Inches) | Center-Face (In Inches) | Radius (In Inches) | Center-Center (In Inches) | Back-face (In Inches) |
| 1/2 | 21.3 | 0.84 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.05 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.66 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.9 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.5 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.5 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.75 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
Copper Buttweld Fittings Tolerance
| Common Type Of Buttweld Fitting | 45 degree elbows And 90 deg elbows | 180 Deg Returns | |||||
|---|---|---|---|---|---|---|---|
| Normal Size Of Steel Pipe | O.D. at Bevel | I.D. at End | WT For (Wall Thickness) t / t1 | Center-End Dai. A-B-C-M | Center-Center Dai. (O) | Back-Face Dai. (K) | Align-ment of Ends (U) |
| 1/2 a 2 1/2 | 1 | 0,8 | Not | 2 | 7 | 7 | 1 |
| 3 a 3 1/2 | 1 | 1,6 | less | 2 | 7 | 7 | 1 |
| 4 | 1 | 1,6 | than | 2 | 7 | 7 | 1 |
| 5 a 6 | 2 | 1,6 | 87,50% | 2 | 7 | 7 | 1 |
| 8 | 2 | 1,6 | of nominal | 2 | 7 | 7 | 1 |
| 10 | 1 | 3,2 | tickness | 2 | 7 | 7 | 2 |
| 12 a 18 | 1 | 3,2 | 3 | 10 | 7 | 2 | |
| 20 a 24 | 1 | 4,8 | 3 | 10 | 7 | 2 | |
| 26 a 30 | 2 | 4,8 | 3 | – | – | – | – |
| 32 a 48 | 2 | 4,8 | 5 | – | – | – | – |
Applications of Copper Buttweld Fittings
Copper Buttweld Fittings are applied in various sectors and structures where copper pipes are required.
- HVAC Systems
- Copper elbows, tees, coupling, reducer, and other fittings are used in HVAC applications to route and connect copper lines.
- Refrigeration Systems
- Copper fittings are common in refrigeration piping to connect and route piping. They can be used in different refrigeration installations due to their thermal properties and compatibility with copper piping.
- Plumbing Systems
- Copper Buttweld Fittings can be used in hot and cold water plumbing systems. Copper has good corrosion resistance and durability, if the right material and installation technique are used.
- Medical Gas Pipeline Systems
- When manufactured and installed to applicable medical-gas requirements, suitable copper piping components can be used in medical gas pipeline systems for medical gases including oxygen, medical air, vacuum and other medical gases.
- Industrial Piping
- Copper fittings are used in certain industrial applications for fluid lines, gas lines, heat-transfer lines and special copper piping lines.
- Heat Transfer Systems
- Copper piping and fittings are appropriate for use in applications where efficient heat transfer is important due to copper’s high thermal conductivity.
- Commercial Buildings
Copper Buttweld Fittings are suitable for commercial building services such as HVAC, refrigeration, plumbing and mechanical piping applications.
