Copper Buttweld Fittings are precision made pipe fittings that are employed for connecting, redirecting, reducing, or terminating copper pipe systems. This type of fitting is used to ensure that the connections are secure and that there are no obstructions in the flow of the pipe.
Kanchan Copper are a Copper Buttweld Fittings Manufacturer & Exporter in Germany which deal in Copper Buttweld Elbows, Tees, Couplings, Reducers, End Cap, Stub Ends, U Bends and Y Bends for various piping needs. Our copper fittings are for use in HVAC, Refrigeration, Plumbing, Medical gas, Industrial and commercial piping.
Kanchan Copper have a wide range of sizes, wall thicknesses, configurations and specifications in Germany that allow to supply our Copper Buttweld Fittings as per project requirements. Our emphasis is on dimensional accuracy, uniformity of manufacture, surface finish and connection performance.
Copper Buttweld Fittings
Copper Buttweld Fittings are used to make butt connections between copper pipes. These fittings are adaptable to the related copper joining and brazing processes as per the application and system requirements.
Copper fittings can be used across a variety of piping systems due to their high thermal conductivity, corrosion resistance and durability. Copper fittings can also offer smooth flow of fluids and gases, thanks to the smooth surface inside the fittings.
Copper Buttweld Fittings Types
Kanchan Copper have various Copper Buttweld Fittings with their use for various piping configurations like Directional Change, Branch Connection, Pipe Size Transition and Pipe End Closure.
Copper Buttweld Elbows Fittings
Copper Buttweld Elbows are a type of elbow that can be used for changing the direction of copper piping systems. They come in various configurations and bend angles, depending on the needs of the piping layout.
Copper elbows are typically used to route copper pipes in HVAC, refrigeration, plumbing, and industrial applications, with 45° and 90° elbows being the most common types.
Copper Buttweld Tees Fittings
Copper Buttweld Tees are used to make a connection from a copper main pipeline. They come in equal and reducing configurations for the desired pipe arrangement.
Copper tees are commonly used where a piping system needs to divide or provide a branch connection to another pipeline.
Copper Buttweld Coupling Fittings
Copper Buttweld Couplings can be utilized to join two copper pipes that are lined up straight. They can be used to lengthen pipes or connect two pipes that are compatible.
They are small enough to be used in a number of copper pipe applications where a straight line connection is desired.
Copper Buttweld End Caps Fittings
Copper Buttweld End Caps are used for both terminating and closing the end of copper pipes. They serve as an appropriate end cap to unused or abandoned portions of pipe.
Copper end caps can be installed in new installations, pipe alterations, maintenance and system extension.
Copper Buttweld Reducers Fittings
Copper Buttweld Reducers are used for joining copper pipes together of varying O.D. They are used in a piping system to switch from larger pipe to smaller pipe.
Reducers are helpful when there is a need to reduce the pipeline size in a very small using a compact and properly aligned connection.
Copper Buttweld Stub Ends Fittings
Copper Buttweld Stub Ends are used in piping systems where a flanged type of connection is needed. They offer an end connection for integration with an appropriate flange set up.
Stub ends may be helpful in a system where portions of the pipe need to be removed, inspected, maintained or replaced.
Copper U Bend Buttweld Fittings
Copper U Bend Buttweld Fittings are U-shaped fittings that are used to create a return bend in a copper piping system.
They are useful when the routing of the piping system demands a compact return path or specific routing. U bends are suitable for HVAC, refrigeration, heat-transfer and other special copper piping applications.
Copper Y Bend Buttweld Fittings
The Copper Y Bend Buttweld Fittings are Y-shaped fitting devices that are made for use in special piping setups.
They can be produced to the desired size and project specifications for specific industrial and copper pipe projects. industrial and copper piping applications.
Copper Buttweld Fittings Specification
Copper Buttweld Fittings can be produced and supplied in various sizes and wall thickness of the different materials and configuration depending on the type of the fitting and the application. Real material grade, size, wall thickness and reference standard can be chosen according to the type of the piping system and customer needs.
| Standard | ASTM B819, EN 1057, EN 13348, ASTM B88 |
|---|---|
| Size | 1/2″ to 24″ NB |
| Thickness | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
| Type | Welded |
| Schedule | SCH 10, SCH 20, SCH 30, SCH 40 |
| Grades | DHP Copper, C10100, C10200, C11000, C12000, C12200 |
| Application | HVAC & Refrigeration, Plumbing, Industrial Piping, Heat Exchangers, Cooling Systems, Engineering Applications |
Copper Buttweld Fittings Pressure Rating Schedule Chart
| NPS (Normal Size Of Steel Pipe) | 10S Sche | 40S Sche | 80S Sche | ||||||
|---|---|---|---|---|---|---|---|---|---|
| 90 Deg Elbow | 45 Deg Elbow | Equal Tee | 90 Deg Elbows | 45 Deg Elbows | Equal Tee | 90 Deg Elbow | 45 Deg Elbow | Equal Tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.1 | 0.1 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.2 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.4 | 0.23 | 0.68 |
| 40 | 0.3 | 0.17 | 0.68 | 0.4 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.5 | 0.25 | 0.85 | 0.7 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.4 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.2 | 1.08 | 3.31 | 2.97 | 1.5 | 4.45 |
| 90 | 1.7 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4 | 2 | 5.44 |
| 100 | 2.1 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.2 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.9 |
| 300 | 25.8 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Copper Elbow Buttweld Fittings size, dimension chart
| NPS For (Normal Size Of Pipe) | O.D. For (Outside Dai.) | BW 90 Deg Elbow | BW 45 Deg Elbow | BW Return 180 Deg Elbow | ||||
|---|---|---|---|---|---|---|---|---|
| BW (Long Radius) Elbow | BW (Short Radius) Elbow | BW (Long Radius) Elbow | BW (Short Radius) Elbow | |||||
| (In Inch) | (MM) | (inch) | Center-Face (Inches) | Center-Face (Inches) | Center-Face (In Inches) | Radius (In Inches) | Center-Center (In Inches) | Back-face (In Inches) |
| 1/2 | 21.3 | 0.84 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.05 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.66 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.9 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.5 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.5 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.75 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
Copper Buttweld Fittings Tolerance
| Common Type Of Buttweld Fitting | 45 degree elbows And 90 deg elbows | 180 Deg Returns | |||||
|---|---|---|---|---|---|---|---|
| Normal Size Of Steel Pipe | O.D. at Bevel | I.D. at End | WT For (Wall Thickness) t / t1 | Center-End Dai. A-B-C-M | Center-Center Dai. (O) | Back-Face Dai. (K) | Align-ment of Ends (U) |
| 1/2 a 2 1/2 | 1 | 0,8 | Not | 2 | 7 | 7 | 1 |
| 3 a 3 1/2 | 1 | 1,6 | less | 2 | 7 | 7 | 1 |
| 4 | 1 | 1,6 | than | 2 | 7 | 7 | 1 |
| 5 a 6 | 2 | 1,6 | 87,50% | 2 | 7 | 7 | 1 |
| 8 | 2 | 1,6 | of nominal | 2 | 7 | 7 | 1 |
| 10 | 1 | 3,2 | tickness | 2 | 7 | 7 | 2 |
| 12 a 18 | 1 | 3,2 | 3 | 10 | 7 | 2 | |
| 20 a 24 | 1 | 4,8 | 3 | 10 | 7 | 2 | |
| 26 a 30 | 2 | 4,8 | 3 | – | – | – | – |
| 32 a 48 | 2 | 4,8 | 5 | – | – | – | – |
Applications of Copper Buttweld Fittings
Copper Buttweld Fittings are applicable in various industries and building services where copper piping systems are needed.
- HVAC Systems
Copper elbows, tees, couplers, reducers and other fittings are used to route and connect copper pipes in HVAC systems. - Refrigeration Systems
Copper fittings are common in refrigerant piping for connecting and routing the refrigerant lines in refrigeration applications. They are used in different refrigeration installations due to their thermal properties and compatibility with copper piping. - Plumbing Systems
Copper Buttweld Fittings can be used in hot and cold water plumbing systems. Under the appropriate selection of material and installation technique, copper gives high corrosion resistance and durability. - Medical Gas Pipeline Systems
- Medical-gas pipeline systems (oxygen, medical air, vacuum, and other medical gases) can be built and installed with suitable copper piping components manufactured and installed to meet applicable medical-gas requirements.
- Industrial Piping
Copper fittings are employed in a few industrial applications such as fluid, gas, heat-transfer, and special copper piping systems. - Heat Transfer Systems
Copper’s thermal conductivity is a characteristic that allows copper piping and fittings to be used in applications that require efficient heat transfer. - Commercial Buildings
Copper Buttweld Fittings are suitable for application in commercial building service as well as HVAC, refrigeration, plumbing and mechanical piping systems.
