Copper Pipes Manufacturer and Exporter in UAE

Kanchan Copper Copper Pipes Industries which is known to produce high-performance solutions needs no introduction to this industry in UAE. Of high repute in terms of quality and consistency, Kanchan Copper Industries is the provider of precision engineered copper piping system that attains international quality standards. The company has gained appreciation in all parts of UAE because of its corrosion-resistant durable products. Kanchan Copper Industries is significant in the contribution towards the infrastructure and utilities projects in the country. Kanchan Copper Industries has not only spread across UAE through its stable logistics and consumer satisfaction.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe Specification :

Copper Alloy Pipe Specification	ASTM B280 ASME SB280 / ASTM B68 ASME SB68
Sizes	Copper Round Pipe Wall thickness: 0.2mm~120mm Outside Diameter: 2mm~910mm
Copper Pipe Schedule	SCH5, SCH10, SCH40, STD, SCH80, SCH160
Copper Welded Pipe size	5.0 mm – 1219.2 mm
Specialized in	Large Diameter Copper Alloy Pipe
Copper Alloy EFW Pipe size	5.0 mm – 1219.2 mm
Copper Pipe Length	Single Random, Double Random & Cut Length.
Material Test Certificates (MTC)	Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2
Marking	All Copper Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.)
Copper Pipe Hardness	1/16 hard, 1/8 hard, 3/8 hard, 1/4 hard, 1/2hard, full hard, soft etc
Copper Pipe Material	T1, T2, C10100, C10200, C10300, C10400, C10500, C10700, C10800, C10910, C10920, TP1, TP2, C10930, C11000, C11300, C11400, C11500, C11600, C12000, C12200, C12300, TU1, TU2, C12500, C14200, C14420, C14500, C14510, C14520, C14530, C17200, C19200, C21000, C23000, C26000, C27000, C27400, C28000, C33000, C33200, C37000, C44300, C44400, C44500, C60800, C63020, C65500, C68700, C70400, C70600, C70620, C71000, C71500, C71520, C71640, C72200, etc.
Copper Pipe Finish	mill, polished, bright, oiled, hair line, brush, mirror, sand blast, or as required.
Copper Alloy Pipe End	Plain End, Beveled End, Treaded.
Copper Alloy Seamless Pipe size	4 to 219mm W. T. : 0.5 to 20mm

Copper Pipes Manufacturer Types, Seamless Copper Tubes Types :

Kanchan Copper Industries Copper Pipes come in different grades and suit different purposes in all industry sectors that exist in UAE. These involve plumbing, HVAC, gas distribution and medical pipeline installations. Kanchan Copper Industries make sure that all kind of copper pipes are of local and global requirements so that they can be used in both residential and industrial purposes in UAE. The extensive product range of Kanchan Copper Industries contributes to the increasing need in the region of the stable and sustainable pipeline systems.

ASTM B 88 – Seamless Copper Water Tube, Type K Copper Pipe:

Kanchan Copper Industries Type K Copper Pipes are rather heavy quality and highly strengthened. These are suitable to use in underground water lines and intense plumbing systems in UAE. They are highly durable thus having long service life even in high-pressure environments. The Kanchan Copper Industries provides a Type K pipe to many utility projects in UAE.

ASTM B 88 – Seamless Copper Water Tube, Type L Copper Pipe:

Kanchan Copper Industries supplies Type L Copper Pipes which is medium in terms of thickness of its structure, making it usable in interior water supply of the buildings and fire protection system of the UAE jurisdiction. They have compromise flexibility and strength which can be used commercially or passively in residential areas. Kanchan Copper Industries is always ready to supply these pipes to the modern building of UAE.

ASTM B 88 – Seamless Copper Water Tube, Type M Copper Pipe:

Kanchan Copper Industries supplies Type M Copper Pipes with less thickness to be used in cost effective plumbing solution in UAE. They are widely applied in low pressure applications and they are simple to fix. Kanchan Copper Industries makes sure they meet the local building requirements and performance standards.

ASTM B819 – Seamless Copper Tube for Medical Gas Systems, Medical Copper Pipe :

Kanchan Copper Industries manufactures the Medical Gas Copper Pipes, which are designed keeping in mind healthcare infrastructure and have ultra clean interiors. These are pipes that facilitate the safe delivery of oxygen and medical gases in the UAE hospitals and clinics. Kanchan Copper Industries also observes the strict requirements of the medical grade quality and testing.

ASTM B 280 – Seamless Copper Tube for Air Conditioning and Refrigeration Field Service, AC Copper Pipes:

Kanchan Copper Industries also produce AC Copper Pipes that are common in HVAC systems which are common in the scorching heat of UAE. These pipes are designed with focus on refrigerant flow, corrosion and efficient heat loss. Kanchan Copper Industries makes it doubly sure to manufacture precisely to fulfil the cooling need in UAE.

Difference Between Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe:

Type	Wall Thickness	Application	Standard	Color Code
Type K	Thickest	Underground, fire systems	ASTM B88	Green
Type L	Medium	Interior plumbing, HVAC	ASTM B88	Blue
Type M	Thinnest	Low-pressure water supply	ASTM B88	Red
Medical Copper	Similar to K/L	Medical gas (cleaned & capped)	ASTM B819	No color (capped ends)
AC Copper Pipe	Variable	Refrigeration & air conditioning	ASTM B280	No color (coil sealed)

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe – Properties of Copper Pipes Manufacturer:

Kanchan Copper Industries manufactures Copper Pipes of high properties required in all sorts of environments of UAE where there is a requirement of long term properties. These pipes are the most mechanically strong, resistant to corrosion and have thermal conductivity. Kanchan Copper industries has a reputation of testing its products in order to satisfy the high local demand standards in the constructions as well as casual industries. These key features have created a favorable supplier of Kanchan Copper Industries across UAE.

• High Corrosion Resistance
  Even the UAE, with its different climatic needs, can use Copper Pipes provided by Kanchan Copper Industries because it is resistant to moisture, chemicals and salts.
• Superb Thermal Conductivity
  Kanchan Copper Industries has a pipe product that has high heat transfer capability which makes it most suitable in HVAC and solar application industries in UAE.
• High Tensile Strength
  Kanchan Copper Industries pipes keep their structures intact even when under stress and pipes will become safe all the water and gas lines in the UAE.
• Toxic-free and Safe
  Kanchan Copper Industries is making sure that its copper pipes are non-toxic and hence safe and ideal in the supply of potable water and medical gases in UAE.
• Long-life quality
  Kanchan Copper Industries Copper Pipes are long lasting to ensure that there are minimal costs of maintenance and of replacements in most of applications used in the UAE.
• Ease of fabrication and Flexibility
  The pipes provided by Kanchan Copper Industries are easy to bend and joint with and this makes them simple to use in any UAE project both in small and large scale developments.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe – Copper Pipes Dimensions, Size and Weight :

Copper Pipes at Kanchan Copper industries are available in vast range of sizes, thickness and diameters so that it can suit all range of working in UAE. The availability of dimensions suitable to the high-rise buildings, hospitals, or industrial buildings is suitable and also appropriate due to the availability of customized measurements that enable it to fit well and perform accordingly. Kanchan Copper industries has a wide storage to supply bulk and customized orders. The availability of the varieties in the weights and sizes enables the customers in UAE to choose the best product to suit their applications without any compromise in its quality and durability.

Type K Copper Pipes Size, Weight and Dimension:

Kanchan Copper Industries is producing Type K Copper Pipes available in various diameters and wall thickness especially made to use underground and high pressure applications in UAE. They come in hard or soft tempers in order to satisfy the different installation demands.

Nominal or standard size (inches)	Nominal dimensions (inches)			Calculated values (based on nominal dimensions)
	Outside diameter	Inside diameter	Wall thickness	Cross sectional area of bore (square inches)	Weight of tube only (lb/ft)	Weight of tube & water (lb/ft)	Volume Contents of tube (per linear foot)
							Cubic feet	Gallon
1/4	0.375	0.305	0.035	0.073	0.133	0.177	0.00051	0.00379
3/8	0.500	0.402	0.049	0.127	0.269	0.324	0.00088	0.00660
1/2	0.625	0.527	0.049	0.218	0.344	0.438	0.00151	0.0113
5/8	0.750	0.652	0.049	0.334	0.418	0.562	0.00232	0.0174
3/4	0.875	0.745	0.065	0.436	0.641	0.829	0.00303	0.0227
1	1.125	0.995	0.065	0.778	0.837	1.18	0.00540	0.0404
1-1/4	1.375	1.245	0.065	1.22	1.04	1.57	0.00847	0.0634
1-1/2	1.625	1.481	0.072	1.72	1.36	2.10	0.0119	0.0894
2	2.125	1.959	0.083	3.01	2.06	3.36	0.0209	0.156
2-1/2	2.625	2.435	0.095	4.66	2.92	4.94	0.0324	0.242
3	3.125	2.907	0.109	6.64	4.00	6.87	0.0461	0.345
3-1/2	3.625	3.385	0.120	9.00	5.12	9.01	0.0625	0.468
4	4.125	3.857	0.134	11.7	6.51	11.6	0.0813	0.608
5	5.125	4.805	0.160	18.1	9.67	17.5	0.126	0.940
6	6.125	5.741	0.192	25.9	13.9	25.1	0.180	1.35
8	8.125	7.583	0.271	45.2	25.9	45.4	0.314	2.35
10	10.125	9.449	0.338	70.1	40.3	70.6	0.487	3.64
12	12.125	11.315	0.405	101	57.8	101	0.701	5.25

Type L Copper Pipes Size, Weight and Dimension:

Kanchan Copper Industries produce Type L Copper Pipes under normal size and custom-made sizes according to the interior plumbing and fire protection system in the UAE. They come in straight and medium wall thickness and coils.

Nominal Size (inches)	Actual Outside Diameter (inches)		Tolerance on Outside Diameter (inches)		Wall Thickness (inches)		Weight (lb/ft)
			Annealed1)	Drawn2)	Nominal	Tolerance
1/4	3/8	0.375	0.002	0.001	0.030	0.003	0.126
3/8	1/2	0.500	0.0025	0.001	0.035	0.004	0.198
1/2	5/8	0.625	0.0025	0.001	0.040	0.004	0.285
5/8	3/4	0.750	0.0025	0.001	0.042	0.004	0.362
3/4	7/8	0.875	0.003	0.001	0.045	0.004	0.455
1	1 1/8	1.125	0.0035	0.0015	0.050	0.005	0.655
1 1/4	1 3/8	1.375	0.004	0.0015	0.055	0.006	0.884
1 1/2	1 5/8	1.625	0.0045	0.002	0.060	0.006	1.14
2	2 1/8	2.125	0.005	0.002	0.070	0.007	1.75
2 1/2	2 5/8	2.625	0.005	0.002	0.080	0.008	2.48
3	3 1/8	3.125	0.005	0.002	0.090	0.009	3.33
3 1/2	3 5/8	3.625	0.005	0.002	0.100	0.010	4.29
4	4 1/8	4.125	0.005	0.002	0.114	0.011	5.38
5	5 1/8	5.125	0.005	0.002	0.125	0.012	7.61
6	6 1/8	6.125	0.005	0.002	0.140	0.014	10.20

Type M Copper Pipes Size, Weight and Dimension:

Kanchan Copper Industries manufactures lighter wall thickness, standard size of Copper Pipes of Type M category to small sized, as well as cost effective and low pressures plumbing system throughout the UAE. These are pipes that can apply in house and small spaces.

Nominal Size (inches)	Actual Outside Diameter (inches)		Tolerance on Outside Diameter (inches)		Wall Thickness (inches)		Weight (lb/ft)
			Annealed1)	Drawn2)	Nominal	Tolerance
1/4	3/8	0.375	0.002	0.001			0.106
3/8	1/2	0.500	0.0025	0.001	0.025	0.002	0.144
1/2	5/8	0.625	0.0025	0.001	0.028	0.003	0.203
5/8	3/4	0.750	0.0025	0.001			0.263
3/4	7/8	0.875	0.003	0.001	0.032	0.003	0.328
1	1 1/8	1.125	0.0035	0.0015	0.035	0.004	0.464
1 1/4	1 3/8	1.375	0.004	0.0015	0.042	0.004	0.681
1 1/2	1 5/8	1.625	0.0045	0.002	0.049	0.005	0.94
2	2 1/8	2.125	0.005	0.002	0.058	0.006	1.46
2 1/2	2 5/8	2.625	0.005	0.002	0.065	0.006	2.03
3	3 1/8	3.125	0.005	0.002	0.072	0.007	2.68
3 1/2	3 5/8	3.625	0.005	0.002	0.083	0.008	3.58
4	4 1/8	4.125	0.005	0.002	0.095	0.010	4.66
5	5 1/8	5.125	0.005	0.002	0.109	0.011	6.66
6	6 1/8	6.125	0.005	0.002	0.122	0.012	8.91

Medical Copper Pipes Size, Weight and Dimension:

Kanchan Copper Industries Medical Copper Pipe are tolerance and measured to ensure that they are more uniform as well as they are consistent with wall thickness. Such pipes are manufactured in the form of sizes that are compatible with international standards of medical gas pipelines installed in the UAE healthcare facilities.

Nominal Outside Diameter (mm)	Tube Length (m)	Wall Thickness (mm)
12	6	0.6
15	3, 6	0.7
22	3, 6	0.9
28	3, 6	0.9
35	6	1.0
42	6	1.0
54	6	1.0
67	6	1.5
76	6	1.5
108	6	1.5
133	6	1.5
159	6	2.0
219	6	3.0

AC Copper Pipe Size, Weight, and Dimensions:

AC Copper Pipes manufactured in Kanchan Copper Industries are available in different sizes and gauges in accordance with the need of the HVAC system in UAE. Their exact dimensions guarantee an optimal flow of refrigerant and compatibility of the system.

Nominal Size (inches)	Annealed (A) or Drawn Temper (D)	Outside Diameter (inches)	Inside Diameter (inches)	Wall Thickness (inches)	Cross Sectional Area of Bore (square inches)
1/8	A	0.125	0.065	0.030	0.0033
3/16	A	0.187	0.128	0.030	0.0129
1/4	A	0.250	0.190	0.030	0.0284
5/16	A	0.312	0.248	0.032	0.0483
3/8	A	0.375	0.311	0.032	0.076
	D	0.375	0.315	0.030	0.078
1/2	A	0.500	0.436	0.032	0.149
	D	0.500	0.430	0.035	0.145
5/8	A	0.625	0.555	0.035	0.242
	D	0.625	0.545	0.040	0.233
3/4	A	0.750	0.680	0.035	0.363
	A	0.750	0.666	0.042	0.348
	D	0.750	0.666	0.042	0.348
7/8	A	0.875	0.785	0.045	0.484
	D	0.875	0.785	0.045	0.484
1 1/8	A	1.125	1.025	0.050	0.825
	D	1.125	1.025	0.050	0.825
1 3/8	A	1.375	1.265	0.055	1.26
	D	1.375	1.265	0.055	1.26

Type K Copper Pipes, Type L Copper Pipes, Type M, Medical Copper Pipe and AC Copper Pipes Chemical Compositions :

Copper Pipes produced in Kanchan Copper Industries contain high-purity level of copper, which is in accordance with the international standards of the composition. This makes it superconductive, strong and resistant to corrosion to all the applications in the UAE.

Copper (Cu) + Silver (Ag)	Phosphorus (P)	Alloy Designation
≥ 99.9% (combined)	0.015% – 0.040% (max)	C12200

Mechanical Properties of Copper Pipes:

The main characteristic of the Copper Pipes manufactured by Kanchan Copper Industries is the good quality of mechanical properties such as tensile strength and elongation. These features guarantee long life sustainability in the harsh conditions in the UAE.

Property	Type K / L / M(ASTM B88)	Medical Copper Pipe(ASTM B819)	ACR Copper Pipe(ASTM B280)
Tensile Strength (min)	210 MPa (Hard) 205 MPa (Annealed)	210 MPa (H58 Temper – Hard)	210 MPa (H58) / 205 MPa (O60)
Yield Strength (min)	69 MPa (Hard) 45 MPa (Annealed)	69 MPa (H58 – Hard)	69 MPa (H58) / 45 MPa (O60)
Elongation (min %)	30% (Annealed) 10% (Hard)	10% (H58 – Hard)	10% (H58), 30% (O60)
Hardness (HR15T)	60–75 (Hard) 45–60 (Annealed)	60–75 (H58 – Hard)	60–75 (H58), 45–60 (O60)

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe Advantages:

Copper Pipes produced by Kanchan Copper industries are highly durable, have excellent thermal conductivity and have long life and hence, they can be used in various processes in UAE. Such pipes need minimum maintenance, easy to install, and they also preserve the purity of water. Kanchan Copper Industries guarantees each pipe in the market to offer good performance in harsh conditions.

• Corrosion and Rust Resistant: Copper Pipes are non-corrosive and non-rusting in nature hence suitable in the humid and saline weather conditions of UAE.
• Thermal Performance: It has great heat conduction which facilitates the effective HVAC and hot water.
• Durability: The material is expected to be durable thus requiring less replacement and repair.
• Fire Resistance: In high temperature fire resistance copper pipes are non-combustible hence safer to use.
• Bacterial Resistance: Inhibits bacterial growth by natural effect thus delivering hygienic water.
• Recyclable: Can be recycled hundred percent of the time and hence is environment friendly.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe Applications:

Kanchan Copper Industries Copper Pipes are applicable in all sizes of copper pipes used in UAE in the various segments such as plumbing and refrigeration, HVAC, gas supply and installations, and medical applications. They can be used in industries and at home since they are reliable and flexible enough. Kanchan copper industries provides copper piping solutions based on their different functional requirements.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe Industrial Applications:

• HVAC Systems: Kanchan Copper Industries offers pipes that are used to facilitate transfer of heat easily and durable pipes that are used in industrial cooling and heating systems in the UAE.
• Oil & Gas Refineries: Copper pipes are applied in high-strength application of the gas distribution pipes and fluid transferring pipes in severe environments.
• Solar Energy Systems: The Copper Pipes allow the best transfer of the energy in the solar water heaters placed in the industries throughout UAE.
• Industrial Water Supply: The continuous water circulation inside the industrial plants is carried out through a strong corrosion free pipes of Kanchan Copper Industries.
• Fire Protection Systems: A fire protection encompasses safety and dependability of sprinklers and fire suppression systems within commercial facilities whose pipes are made using copper.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe General Applications:

• Residential plumbing: Kanchan Copper Industries also supplies pipes in potable water system, which guarantees hygiene and durability of the system in the homes in the UAE.
• Medical Gas Lines: The medical-grade copper pipes of the hospitals and the clinics ensure gas delivery systems.
• Air Conditioning Systems: Those systems are common in residential and commercial air conditioners to provide an effective transportation of the refrigerant.
• Building Gas Piping: Building gas and long-lasting gas supply in the kitchens and appliances.
• Hot and Cold Water Distribution: The pipes made by Kanchan Copper Industries are ideal in supplying domestic water, as it would maintain a steady flow and remain heat-efficient.
