Copper Pipes Manufacturer and Exporter in Spain

Kanchan Copper Industries is one of the well-known Copper Pipes manufactures, and exporters situated in Spain with the reputation of best quality Copper Pipes and other industrial, medical, and commercial needs. Kanchan Copper Industries has a solid reputation throughout Spain and it provides high-quality systems of copper bragging which are perfect-engineered. The copper pipes offered by the company are very strong, of high performance and non-corrosive. Kanchan Copper Industries has a wide range of branches mainly in HVAC, medical gas pipeline and residential plumbing. The increasing span in Spain is an indication that the company is dedicated to reliability and a long term relationship with partners.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe Specification :

Copper Alloy Pipe Specification	ASTM B280 ASME SB280 / ASTM B68 ASME SB68
Sizes	Copper Round Pipe Wall thickness: 0.2mm~120mm Outside Diameter: 2mm~910mm
Copper Pipe Schedule	SCH5, SCH10, SCH40, STD, SCH80, SCH160
Copper Welded Pipe size	5.0 mm – 1219.2 mm
Specialized in	Large Diameter Copper Alloy Pipe
Copper Alloy EFW Pipe size	5.0 mm – 1219.2 mm
Copper Pipe Length	Single Random, Double Random & Cut Length.
Material Test Certificates (MTC)	Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2
Marking	All Copper Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.)
Copper Pipe Hardness	1/16 hard, 1/8 hard, 3/8 hard, 1/4 hard, 1/2hard, full hard, soft etc
Copper Pipe Material	T1, T2, C10100, C10200, C10300, C10400, C10500, C10700, C10800, C10910, C10920, TP1, TP2, C10930, C11000, C11300, C11400, C11500, C11600, C12000, C12200, C12300, TU1, TU2, C12500, C14200, C14420, C14500, C14510, C14520, C14530, C17200, C19200, C21000, C23000, C26000, C27000, C27400, C28000, C33000, C33200, C37000, C44300, C44400, C44500, C60800, C63020, C65500, C68700, C70400, C70600, C70620, C71000, C71500, C71520, C71640, C72200, etc.
Copper Pipe Finish	mill, polished, bright, oiled, hair line, brush, mirror, sand blast, or as required.
Copper Alloy Pipe End	Plain End, Beveled End, Treaded.
Copper Alloy Seamless Pipe size	4 to 219mm W. T. : 0.5 to 20mm

Copper Pipes Manufacturer Types, Seamless Copper Tubes Types :

The Kanchan Copper Industries has a vast variety of the types of copper pipes to cater to various needs in Spain. All variations are designed to correlate with varied pressure ratings, environment of installation, and application requirements. Each product of the company is designed with accuracy and dependability. Kanchan Copper Industries is popularly selected in Spain because of its consistency in production of quality in all categories of pipes.

ASTM B 88 – Seamless Copper Water Tube, Type K Copper Pipe:

Kanchan Copper Industries produce Type K Copper Pipe which has the thickest wall which is suitable when it comes to underground water lines in Spain. It has great pressure-handling abilities and can resist corrosion, which makes it suitable in the municipal and industrial piping system. It is mostly applied in locations requiring durable and strong pipes. Kanchan Copper Industries maintains the consistency in the thickness and flawless design in Spain.

ASTM B 88 – Seamless Copper Water Tube, Type L Copper Pipe:

Kanchan Copper industries Type L Copper Pipes are widely applied in the residential and commercial water passage systems in Spain. These pipes give a compromise of strength and flexibility, hence suited to deliver both hot and cold water. Their flexibilities to resist moderate pressure makes them be in demand in building construction. Kanchan Copper industries ensures consistency in production to make sure reliability can be supplied in the long term.

ASTM B 88 – Seamless Copper Water Tube, Type M Copper Pipe:

Kanchan Copper Industries manufactures value-added Type M Copper Pipes to non-pressurized systems in Spain. They are also thinner and cheaper, and they are only suited in lower-pressure residential water pipes and vent lines. They are made in a manner that they accurately work even though they are thinner. Kanchan Copper Industries is reliable and easy to install in any particular piece.

ASTM B819 – Seamless Copper Tube for Medical Gas Systems, Medical Copper Pipe :

Kanchan Copper Industries also provides Medical Gas Copper Pipes which is specifically made to provide hospital and medical infrastructure in Spain. Such pipes are degreased, cleaned and packed according to the international medical standards. Their interior is contamination-free and the conductivity is superior, which favors reliable medical gas delivery. Pipe systems manufactured in Kanchan Copper Industries are found to be safe and hygienic to the hospitals around Spain.

ASTM B 280 – Seamless Copper Tube for Air Conditioning and Refrigeration Field Service, AC Copper Pipes:

Kanchan Copper Industries have copper pipes called AC Copper Pipes that are also largely used in the HVAC and refrigeration division in Spain. They have a high thermal conductivity and corrosion resistance and can be effectively used in the air conditioning and refrigeration lines. To ensure effective cooling activities, smooth finishes and accurate dimensions are given by the company. HVAC contractors all over Spain prefer to work with Kanchan Copper Industries.

Difference Between Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe:

Type	Wall Thickness	Application	Standard	Color Code
Type K	Thickest	Underground, fire systems	ASTM B88	Green
Type L	Medium	Interior plumbing, HVAC	ASTM B88	Blue
Type M	Thinnest	Low-pressure water supply	ASTM B88	Red
Medical Copper	Similar to K/L	Medical gas (cleaned & capped)	ASTM B819	No color (capped ends)
AC Copper Pipe	Variable	Refrigeration & air conditioning	ASTM B280	No color (coil sealed)

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe – Properties of Copper Pipes Manufacturer:

Kanchan Copper Industries believes in quality and performance by all copper pipes delivered in Spain. The characteristics of copper pipes are part and parcel of effective or efficient use of the copper pipes in plumbing, HVAC, and industrial applications. Kanchan Copper Industries provides its copper pipes with long durability along with efficiency and safety in different sectors of Spain. The properties themselves contribute to sustainable growth of infrastructure in Spain.

• High Durability : Kanchan Copper Industries produces copper pipes which can last decades of use even in harsh Spanish conditions. Wear resistance property and resistance to deformation format decreases on-going maintenance.
• Superior Corrosion Protection : The copper pipes manufactured by Kanchan Copper Industries are also very resistant to corrosion and they can be used both in buried as well as exposed areas in Spain. This attribute guarantees continuity as well as safety.
• High thermal conductivity : Kanchan Copper Industries has pipes that have excellent thermal conductivity, which are much needed in the HVAC system and heating purposes in Spain. It makes the system configuration energy efficient.
• Easy Formability and Flexibility : Kanchan Copper Industries offers copper pipes which are easy to bend and twist so that the complicated installations can be done. The flexibility assists in decreasing the joins and the chances of leaks in Spanish infrastructure.
• Leak-Proof and Hygienic : Kanchan Copper Industries produces a pipe which is not prone to leakages and thus can be used in supply of potable waters in the regions of Spain. Their antibiotic covering helps in the provision of clean water.
• Fire and heat resistance : Copper pipes that are produced by Kanchan copper industry are inherently fireproof and therein they also do not collapse due to intense heat. They are hence perfect in safety applications executed in Spain.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe – Copper Pipes Dimensions, Size and Weight :

Kanchan Copper Industries provides copper pipes of wide array of sizes, weights and thickness of walls to accommodate various installation requirements in the whole of Spain. Regardless of the application in industrial pressure systems, residential plumbing, or medical gas lines, the range will guarantee overlooked accuracy in fit and compatibility as well as unsurpassed performance of all the applications.

Type K Copper Pipes Size, Weight and Dimension:

Kanchan Copper Industries offer Type K Copper Pipes in thick-walled type which is suitable to be utilized in high-pressure and underground applications in Spain. The various sizes make the items reliable in challenging environments.

Nominal or standard size (inches)	Nominal dimensions (inches)			Calculated values (based on nominal dimensions)
	Outside diameter	Inside diameter	Wall thickness	Cross sectional area of bore (square inches)	Weight of tube only (lb/ft)	Weight of tube & water (lb/ft)	Volume Contents of tube (per linear foot)
							Cubic feet	Gallon
1/4	0.375	0.305	0.035	0.073	0.133	0.177	0.00051	0.00379
3/8	0.500	0.402	0.049	0.127	0.269	0.324	0.00088	0.00660
1/2	0.625	0.527	0.049	0.218	0.344	0.438	0.00151	0.0113
5/8	0.750	0.652	0.049	0.334	0.418	0.562	0.00232	0.0174
3/4	0.875	0.745	0.065	0.436	0.641	0.829	0.00303	0.0227
1	1.125	0.995	0.065	0.778	0.837	1.18	0.00540	0.0404
1-1/4	1.375	1.245	0.065	1.22	1.04	1.57	0.00847	0.0634
1-1/2	1.625	1.481	0.072	1.72	1.36	2.10	0.0119	0.0894
2	2.125	1.959	0.083	3.01	2.06	3.36	0.0209	0.156
2-1/2	2.625	2.435	0.095	4.66	2.92	4.94	0.0324	0.242
3	3.125	2.907	0.109	6.64	4.00	6.87	0.0461	0.345
3-1/2	3.625	3.385	0.120	9.00	5.12	9.01	0.0625	0.468
4	4.125	3.857	0.134	11.7	6.51	11.6	0.0813	0.608
5	5.125	4.805	0.160	18.1	9.67	17.5	0.126	0.940
6	6.125	5.741	0.192	25.9	13.9	25.1	0.180	1.35
8	8.125	7.583	0.271	45.2	25.9	45.4	0.314	2.35
10	10.125	9.449	0.338	70.1	40.3	70.6	0.487	3.64
12	12.125	11.315	0.405	101	57.8	101	0.701	5.25

Type L Copper Pipes Size, Weight and Dimension:

Kanchan Copper Industries Type L Copper Pipes are of medium thickness of the wall that provides flexibility at the places of installation without compromising the strength which is generally applicable in the building systems of Spain.

Nominal Size (inches)	Actual Outside Diameter (inches)		Tolerance on Outside Diameter (inches)		Wall Thickness (inches)		Weight (lb/ft)
			Annealed1)	Drawn2)	Nominal	Tolerance
1/4	3/8	0.375	0.002	0.001	0.030	0.003	0.126
3/8	1/2	0.500	0.0025	0.001	0.035	0.004	0.198
1/2	5/8	0.625	0.0025	0.001	0.040	0.004	0.285
5/8	3/4	0.750	0.0025	0.001	0.042	0.004	0.362
3/4	7/8	0.875	0.003	0.001	0.045	0.004	0.455
1	1 1/8	1.125	0.0035	0.0015	0.050	0.005	0.655
1 1/4	1 3/8	1.375	0.004	0.0015	0.055	0.006	0.884
1 1/2	1 5/8	1.625	0.0045	0.002	0.060	0.006	1.14
2	2 1/8	2.125	0.005	0.002	0.070	0.007	1.75
2 1/2	2 5/8	2.625	0.005	0.002	0.080	0.008	2.48
3	3 1/8	3.125	0.005	0.002	0.090	0.009	3.33
3 1/2	3 5/8	3.625	0.005	0.002	0.100	0.010	4.29
4	4 1/8	4.125	0.005	0.002	0.114	0.011	5.38
5	5 1/8	5.125	0.005	0.002	0.125	0.012	7.61
6	6 1/8	6.125	0.005	0.002	0.140	0.014	10.20

Type M Copper Pipes Size, Weight and Dimension:

Kanchan Copper Industries provides lighter weights and thinner walled Type M Copper Pipes that are used in low-pressure and low cost plumbing across Spain.

Nominal Size (inches)	Actual Outside Diameter (inches)		Tolerance on Outside Diameter (inches)		Wall Thickness (inches)		Weight (lb/ft)
			Annealed1)	Drawn2)	Nominal	Tolerance
1/4	3/8	0.375	0.002	0.001			0.106
3/8	1/2	0.500	0.0025	0.001	0.025	0.002	0.144
1/2	5/8	0.625	0.0025	0.001	0.028	0.003	0.203
5/8	3/4	0.750	0.0025	0.001			0.263
3/4	7/8	0.875	0.003	0.001	0.032	0.003	0.328
1	1 1/8	1.125	0.0035	0.0015	0.035	0.004	0.464
1 1/4	1 3/8	1.375	0.004	0.0015	0.042	0.004	0.681
1 1/2	1 5/8	1.625	0.0045	0.002	0.049	0.005	0.94
2	2 1/8	2.125	0.005	0.002	0.058	0.006	1.46
2 1/2	2 5/8	2.625	0.005	0.002	0.065	0.006	2.03
3	3 1/8	3.125	0.005	0.002	0.072	0.007	2.68
3 1/2	3 5/8	3.625	0.005	0.002	0.083	0.008	3.58
4	4 1/8	4.125	0.005	0.002	0.095	0.010	4.66
5	5 1/8	5.125	0.005	0.002	0.109	0.011	6.66
6	6 1/8	6.125	0.005	0.002	0.122	0.012	8.91

Medical Copper Pipes Size, Weight and Dimension:

Kanchan Copper Industries produce medical copper pipes of accordance with the standards of the healthcare industry of Spain with clean finishes and controlled dimensions.

Nominal Outside Diameter (mm)	Tube Length (m)	Wall Thickness (mm)
12	6	0.6
15	3, 6	0.7
22	3, 6	0.9
28	3, 6	0.9
35	6	1.0
42	6	1.0
54	6	1.0
67	6	1.5
76	6	1.5
108	6	1.5
133	6	1.5
159	6	2.0
219	6	3.0

AC Copper Pipe Size, Weight, and Dimensions:

Kanchan Copper Industries provides AC Copper Pipes in special outer diameters and weights intended to HVAC and refrigeration application so that AC Copper Pipes can produce consistent and efficient cooling performance in Spain.

Nominal Size (inches)	Annealed (A) or Drawn Temper (D)	Outside Diameter (inches)	Inside Diameter (inches)	Wall Thickness (inches)	Cross Sectional Area of Bore (square inches)
1/8	A	0.125	0.065	0.030	0.0033
3/16	A	0.187	0.128	0.030	0.0129
1/4	A	0.250	0.190	0.030	0.0284
5/16	A	0.312	0.248	0.032	0.0483
3/8	A	0.375	0.311	0.032	0.076
	D	0.375	0.315	0.030	0.078
1/2	A	0.500	0.436	0.032	0.149
	D	0.500	0.430	0.035	0.145
5/8	A	0.625	0.555	0.035	0.242
	D	0.625	0.545	0.040	0.233
3/4	A	0.750	0.680	0.035	0.363
	A	0.750	0.666	0.042	0.348
	D	0.750	0.666	0.042	0.348
7/8	A	0.875	0.785	0.045	0.484
	D	0.875	0.785	0.045	0.484
1 1/8	A	1.125	1.025	0.050	0.825
	D	1.125	1.025	0.050	0.825
1 3/8	A	1.375	1.265	0.055	1.26
	D	1.375	1.265	0.055	1.26

Type K Copper Pipes, Type L Copper Pipes, Type M, Medical Copper Pipe and AC Copper Pipes Chemical Compositions :

Kanchan Copper Industries Copper Pipes are produced with high purity copper which makes them have higher conductivity as well as resistance to corrosion which is vital in their effective use in Spain.

Copper (Cu) + Silver (Ag)	Phosphorus (P)	Alloy Designation
≥ 99.9% (combined)	0.015% – 0.040% (max)	C12200

Mechanical Properties of Copper Pipes:

Kanchan Copper Industries guarantees high tensile strength, elongation and hardness scores of its copper pipes so that its long-term mechanical output is upheld in several Spanish installations.

Property	Type K / L / M(ASTM B88)	Medical Copper Pipe(ASTM B819)	ACR Copper Pipe(ASTM B280)
Tensile Strength (min)	210 MPa (Hard) 205 MPa (Annealed)	210 MPa (H58 Temper – Hard)	210 MPa (H58) / 205 MPa (O60)
Yield Strength (min)	69 MPa (Hard) 45 MPa (Annealed)	69 MPa (H58 – Hard)	69 MPa (H58) / 45 MPa (O60)
Elongation (min %)	30% (Annealed) 10% (Hard)	10% (H58 – Hard)	10% (H58), 30% (O60)
Hardness (HR15T)	60–75 (Hard) 45–60 (Annealed)	60–75 (H58 – Hard)	60–75 (H58), 45–60 (O60)

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe Advantages:

Kanchan copper industries provide copper pipes that are long-term durable, anti-corrosive, and easy to install which is why they are very desired in Spain. These are recyclable pipes, which are safe in terms of potable water, and which favor high thermal performance. Kanchan Copper Industries guarantees the international quality standard on various fields. Their flexibility towards commercial and industrial systems also is of much value.

So why copper pipes?

• Corrosion Resistance : Copper pipes of Kanchan Copper Industries are resistant to internal and external corrosions thus guaranteeing long service life and even in a harsh environment or humid atmosphere in Spain.
• Thermal Conductivity : The pipes have great capability of heat transfer and will suit HVAC and heating systems to save on energy.
• Non-toxic and Safe : Pipes used are lead-free and do not react with drinking water used throughout Spain.
• Long-Term Reliability : Kanchan Copper industries provide high fatigue strength and strength of copper pipes so that that the cost of maintenance will be low in the long run.
• Simple to install and join : Copper pipes have the advantage of flexibility and ease of workmanship in term of reducing the time of pipe installations and minimal fittings to reduce chances of leakage.
• Environmentally Friendly : Copper is 100 percent recyclable, and this facilitates sustainability in present infrastructure undertakings in Spain.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe Applications:

Kanchan Copper Industries Copper Pipes are extensively used in residential, commercial and industrial units in Spain. In plumbing and medical gas lines, refrigeration, and HVAC systems these pipes play a critical role. They are very versatile, dependable and safe and therefore, they are popular in new and refurbishment activities.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe Industrial Applications:

• HVAC Systems :
  Kanchan Copper Industries copper pipes are installed on the heating, ventilating and air conditioning systems of the commercial and industrial buildings in Spain, since copper pipes are thermally conductive and long lasting materials.
• Medical Gas Systems :
  Hospitals and medical centers around Spain use Kanchan Copper Industries medical grade of copper pipes to deliver gas through safe and contamination-free gas delivery systems as per the health and safety regulations.
• Refrigeration Systems :
  Kanchan Copper Industries copper pipes can be used in cooling and refrigeration industry in the industrial segments where leak-free and corrosion free solutions can be provided for uninterrupted operation.
• Desalination and Water Treatment Plants :
  Copper anti-bacterial capability renders these pipes to be suitable as water purification and desalination plants in Spain, so as to maintain hygiene and effective flow.
• Industrial plumbing Networks :
  Kanchan Copper Industries has been providing industrial fluid transport systems, non-insulated high-pressure copper pipes, with a stable performance at the factories and processing plants in Spain.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe General Applications:

• Residential Plumbing :
  The pipes provided by Kanchan Copper Industries to plumbing in the kitchens, bathrooms and utility centers are safe and durable, which makes the pipes preferred by the homeowners of Spain since they can be easily installed and will not leak water.
• Gas Distribution :
  The domestic gas pipelines that are laid in Spain use copper pipes of the Kanchan Copper Industries which are strong, reliable and can endure high pressure and heat.
• Air Conditioning Units :
  These pipes are part and parcel of the AC units in homes and offices whereby, efficient refrigerant accessibility and cooling is done without energy wastage.
• Underfloor heating systems :
  Kanchan Copper Industries offer thin but powerful copper pipe that is used in underfloor heating system and it balances the heat in the houses that are located in Spain.
• Fire Sprinkler :
  The safety and durability of copper in buildings relates to the construction of fire suppression systems using the pipes, with copies of these being constructed on residential complexes across Spain. This is because copper is non-combustible.
