Copper Pipes Manufacturer and Exporter in Maldives

Kanchan Copper Industries is a reputed company dealing in producing and exporting high quality Copper pipes in Maldives. Our copper piping systems are renowned to be of high precision all over the world due to precision engineering. Kanchan Copper Industries provides long lasting, heat resistant, corrosion free pipes that are tailor made to the requirements of Maldivian market. Some of the industries we work on are HVAC, plumbing, medical gas systems, etc. Kanchan Copper Industries has established a firm foundation in Maldives due to its concurrent performance of its products.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe Specification :

Copper Alloy Pipe Specification	ASTM B280 ASME SB280 / ASTM B68 ASME SB68
Sizes	Copper Round Pipe Wall thickness: 0.2mm~120mm Outside Diameter: 2mm~910mm
Copper Pipe Schedule	SCH5, SCH10, SCH40, STD, SCH80, SCH160
Copper Welded Pipe size	5.0 mm – 1219.2 mm
Specialized in	Large Diameter Copper Alloy Pipe
Copper Alloy EFW Pipe size	5.0 mm – 1219.2 mm
Copper Pipe Length	Single Random, Double Random & Cut Length.
Material Test Certificates (MTC)	Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2
Marking	All Copper Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.)
Copper Pipe Hardness	1/16 hard, 1/8 hard, 3/8 hard, 1/4 hard, 1/2hard, full hard, soft etc
Copper Pipe Material	T1, T2, C10100, C10200, C10300, C10400, C10500, C10700, C10800, C10910, C10920, TP1, TP2, C10930, C11000, C11300, C11400, C11500, C11600, C12000, C12200, C12300, TU1, TU2, C12500, C14200, C14420, C14500, C14510, C14520, C14530, C17200, C19200, C21000, C23000, C26000, C27000, C27400, C28000, C33000, C33200, C37000, C44300, C44400, C44500, C60800, C63020, C65500, C68700, C70400, C70600, C70620, C71000, C71500, C71520, C71640, C72200, etc.
Copper Pipe Finish	mill, polished, bright, oiled, hair line, brush, mirror, sand blast, or as required.
Copper Alloy Pipe End	Plain End, Beveled End, Treaded.
Copper Alloy Seamless Pipe size	4 to 219mm W. T. : 0.5 to 20mm

Copper Pipes Manufacturer Types, Seamless Copper Tubes Types :

Kanchan Copper Industries has the complete variety of copper pipes that meet all the technical and functional purposes of Maldives. They are produced with accurate dimensions and best raw materials which cater to the use in the plumbing, air conditioning, refrigeration and medical gas systems. Kanchan Copper Industries, makes sure that all the types of pipes are well suited with the international and Maldivian market demand.

ASTM B 88 – Seamless Copper Water Tube, Type K Copper Pipe:

Kanchan copper industries produce K type of copper pipes which have the thickest walls as compared to other pipes that are made of copper. They are suitable in areas where high pressures are required like underground water lines and fluid distribution of industry in Maldives. They are durable and highly corrosive resistant hence suitable in long term infrastructure. Kanchan copper industries supply them in a rigid as well as flexible form that can be used anywhere.

ASTM B 88 – Seamless Copper Water Tube, Type L Copper Pipe:

Kanchan Copper industries type L Copper Pipes find a large use in residential and commercial water supply structures in Maldives. The pipes are found in the middle between strength and flexibility, and hence suitable in interior plumbing and fire protection systems. Thickness of the wall is moderate enough to provide trustworthy performance and at the same time be economical. Kanchan Copper Industries ensures that quality and its consistency is met in line with international standards.

ASTM B 88 – Seamless Copper Water Tube, Type M Copper Pipe:

Kanchan Copper industries manufacture Type M Copper Pipes that are famous to be light in structure and cheap. They are better in low-pressure plumbing in residential setting in Maldives because they are reliable and cost effective. They are thinner than Type L yet of adequate durability to serve as indoor water distribution. Kanchan Copper Industries has the rigorous quality check in order to sustain the performance of each unit.

ASTM B819 – Seamless Copper Tube for Medical Gas Systems, Medical Copper Pipe :

Kanchan Copper Industries deals in Medical Gas Copper Pipes that are meant to be used in health care in Maldives. Such pipes get to be degreased and cleaned to high standards of oxygen and other medical gases. The company adheres to the international standards so as to have the contamination free delivery systems. Kanchan Copper Industries manufacturing company is a reputable brand when it comes to medical piping copper in the Maldives.

ASTM B 280 – Seamless Copper Tube for Air Conditioning and Refrigeration Field Service, AC Copper Pipes:

Kanchan Copper Industries is a high-performance producer of AC Copper Pipes used in Air conditioning and refrigeration systems in Maldives. They are well designed in terms of withstanding pressure and thermal conductivity thus they are perfect in HVAC. They are well polished inside and they have minimal energy to leak out and they have good distribution of the refrigerant. Kanchan Copper Industries supplies such pipes at a customized length and specification demanding the market.

Difference Between Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe:

Type	Wall Thickness	Application	Standard	Color Code
Type K	Thickest	Underground, fire systems	ASTM B88	Green
Type L	Medium	Interior plumbing, HVAC	ASTM B88	Blue
Type M	Thinnest	Low-pressure water supply	ASTM B88	Red
Medical Copper	Similar to K/L	Medical gas (cleaned & capped)	ASTM B819	No color (capped ends)
AC Copper Pipe	Variable	Refrigeration & air conditioning	ASTM B280	No color (coil sealed)

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe – Properties of Copper Pipes Manufacturer:

Kanchan Copper Industries produces Copper Pipes with excellent mechanical and thermal properties which renders them in applications that are intended to be critical in Maldives. The pipes are characterized with high resistance to corrosion, good conductivity, and integrity, and hence they will serve consistently regardless of the different environmental conditions. Such properties are important in a coastal settlement such as Maldives in order to have a long-term plumbing, HVAC and medical gas systems. Kanchan Copper Industries prides in the fact that each and every copper pipe produced in the industries is manufactured to satisfy rigorous local and industrial specifications.

• Corrosion Resistance:
  Copper Pipes manufactured by Kanchan Copper Industries are very much resistant to corrosion, particularly in salty and wet places such as in Maldives. This makes this property last long on underground applications as well as exposed ones.
• Good Thermal Conductivity:
  Heat transfer is easily achieved through copper advantages of high thermal conductivity and this is important to a HVAC system in Maldives. It also promotes energy saving operation of refrigeration and air conditioning machine.
• Excellent Malleability and flexibility:
  The pipes produced by Kanchan Copper Industries bend and shape easily and do not crack, hence the suitability of their use in the customization of plumbing systems in the residential and commercial premises.
• Endurance of High Pressure:
  The high internal pressure could be tolerated by Copper Pipes and it can be used in the potable water lines, fire protection systems, and medical gas distribution networks. The latter will be safe to use and perform well under harsh consumption.
• Long Life span:
  Copper pipes have a life span of more than 50 years due to their little maintenance and very high withstanding levels to environmental abuse. Kanchan Copper Industries guarantees stability in the infrastructure life in Maldives.
• Non Toxic and Safe:
  Copper is inherently antimicrobial and does not leach toxic elements, and it is perfect to use in the fields of drinking water and healthcare. Kanchan Copper Industries have purity of medical as well as plumbing grade copper.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe – Copper Pipes Dimensions, Size and Weight :

Kanchan Copper Industries provides Copper Pipes in large extent of size, thickness and weight to avoid the requirement of installation which varies and pressure varies. That being the case and that is why this flexibility in size now brings about the fact that project designers in Maldives are able to select the most appropriate pipe depending on the application area which can be the light weight home piping to the heavy-duty industrial and medical piping. Be it a small indoor facility or a large-sized pipeline, our copper pipe lines fit perfectly into the application and promise well.

Type K Copper Pipes Size, Weight and Dimension:

The Kanchan Copper Industries also supplies the Type K Copper Pipes in thick-wall form that is most suitable in the high-pressure and underground applications comes in both hard and soft tempers.

Nominal or standard size (inches)	Nominal dimensions (inches)			Calculated values (based on nominal dimensions)
	Outside diameter	Inside diameter	Wall thickness	Cross sectional area of bore (square inches)	Weight of tube only (lb/ft)	Weight of tube & water (lb/ft)	Volume Contents of tube (per linear foot)
							Cubic feet	Gallon
1/4	0.375	0.305	0.035	0.073	0.133	0.177	0.00051	0.00379
3/8	0.500	0.402	0.049	0.127	0.269	0.324	0.00088	0.00660
1/2	0.625	0.527	0.049	0.218	0.344	0.438	0.00151	0.0113
5/8	0.750	0.652	0.049	0.334	0.418	0.562	0.00232	0.0174
3/4	0.875	0.745	0.065	0.436	0.641	0.829	0.00303	0.0227
1	1.125	0.995	0.065	0.778	0.837	1.18	0.00540	0.0404
1-1/4	1.375	1.245	0.065	1.22	1.04	1.57	0.00847	0.0634
1-1/2	1.625	1.481	0.072	1.72	1.36	2.10	0.0119	0.0894
2	2.125	1.959	0.083	3.01	2.06	3.36	0.0209	0.156
2-1/2	2.625	2.435	0.095	4.66	2.92	4.94	0.0324	0.242
3	3.125	2.907	0.109	6.64	4.00	6.87	0.0461	0.345
3-1/2	3.625	3.385	0.120	9.00	5.12	9.01	0.0625	0.468
4	4.125	3.857	0.134	11.7	6.51	11.6	0.0813	0.608
5	5.125	4.805	0.160	18.1	9.67	17.5	0.126	0.940
6	6.125	5.741	0.192	25.9	13.9	25.1	0.180	1.35
8	8.125	7.583	0.271	45.2	25.9	45.4	0.314	2.35
10	10.125	9.449	0.338	70.1	40.3	70.6	0.487	3.64
12	12.125	11.315	0.405	101	57.8	101	0.701	5.25

Type L Copper Pipes Size, Weight and Dimension:

Type L Copper Pipes are medium wall thickness with different diameters, which are applicable in interior plumbing and fire protection in the Maldives construction systems.

Nominal Size (inches)	Actual Outside Diameter (inches)		Tolerance on Outside Diameter (inches)		Wall Thickness (inches)		Weight (lb/ft)
			Annealed1)	Drawn2)	Nominal	Tolerance
1/4	3/8	0.375	0.002	0.001	0.030	0.003	0.126
3/8	1/2	0.500	0.0025	0.001	0.035	0.004	0.198
1/2	5/8	0.625	0.0025	0.001	0.040	0.004	0.285
5/8	3/4	0.750	0.0025	0.001	0.042	0.004	0.362
3/4	7/8	0.875	0.003	0.001	0.045	0.004	0.455
1	1 1/8	1.125	0.0035	0.0015	0.050	0.005	0.655
1 1/4	1 3/8	1.375	0.004	0.0015	0.055	0.006	0.884
1 1/2	1 5/8	1.625	0.0045	0.002	0.060	0.006	1.14
2	2 1/8	2.125	0.005	0.002	0.070	0.007	1.75
2 1/2	2 5/8	2.625	0.005	0.002	0.080	0.008	2.48
3	3 1/8	3.125	0.005	0.002	0.090	0.009	3.33
3 1/2	3 5/8	3.625	0.005	0.002	0.100	0.010	4.29
4	4 1/8	4.125	0.005	0.002	0.114	0.011	5.38
5	5 1/8	5.125	0.005	0.002	0.125	0.012	7.61
6	6 1/8	6.125	0.005	0.002	0.140	0.014	10.20

Type M Copper Pipes Size, Weight and Dimension:

Providing light weight Type M Copper Pipes in thin walls, used in low pressure applications, with cheapest rates and ready to be used, Kanchan Copper industries gives these copper pipes.

Nominal Size (inches)	Actual Outside Diameter (inches)		Tolerance on Outside Diameter (inches)		Wall Thickness (inches)		Weight (lb/ft)
			Annealed1)	Drawn2)	Nominal	Tolerance
1/4	3/8	0.375	0.002	0.001			0.106
3/8	1/2	0.500	0.0025	0.001	0.025	0.002	0.144
1/2	5/8	0.625	0.0025	0.001	0.028	0.003	0.203
5/8	3/4	0.750	0.0025	0.001			0.263
3/4	7/8	0.875	0.003	0.001	0.032	0.003	0.328
1	1 1/8	1.125	0.0035	0.0015	0.035	0.004	0.464
1 1/4	1 3/8	1.375	0.004	0.0015	0.042	0.004	0.681
1 1/2	1 5/8	1.625	0.0045	0.002	0.049	0.005	0.94
2	2 1/8	2.125	0.005	0.002	0.058	0.006	1.46
2 1/2	2 5/8	2.625	0.005	0.002	0.065	0.006	2.03
3	3 1/8	3.125	0.005	0.002	0.072	0.007	2.68
3 1/2	3 5/8	3.625	0.005	0.002	0.083	0.008	3.58
4	4 1/8	4.125	0.005	0.002	0.095	0.010	4.66
5	5 1/8	5.125	0.005	0.002	0.109	0.011	6.66
6	6 1/8	6.125	0.005	0.002	0.122	0.012	8.91

Medical Copper Pipes Size, Weight and Dimension:

Kanchan Copper Industries provide Medical Copper Pipes in degreased, cleaned forms with precise dimensional uniformity of the hospital and health care pipelines in Maldives.

Nominal Outside Diameter (mm)	Tube Length (m)	Wall Thickness (mm)
12	6	0.6
15	3, 6	0.7
22	3, 6	0.9
28	3, 6	0.9
35	6	1.0
42	6	1.0
54	6	1.0
67	6	1.5
76	6	1.5
108	6	1.5
133	6	1.5
159	6	2.0
219	6	3.0

AC Copper Pipe Size, Weight, and Dimensions:

AC Copper Pipes are produced in the standard HVAC sized diameters and thickness of the pipes to promote the smooth flow of the refrigerant within an air conditioning system.

Nominal Size (inches)	Annealed (A) or Drawn Temper (D)	Outside Diameter (inches)	Inside Diameter (inches)	Wall Thickness (inches)	Cross Sectional Area of Bore (square inches)
1/8	A	0.125	0.065	0.030	0.0033
3/16	A	0.187	0.128	0.030	0.0129
1/4	A	0.250	0.190	0.030	0.0284
5/16	A	0.312	0.248	0.032	0.0483
3/8	A	0.375	0.311	0.032	0.076
	D	0.375	0.315	0.030	0.078
1/2	A	0.500	0.436	0.032	0.149
	D	0.500	0.430	0.035	0.145
5/8	A	0.625	0.555	0.035	0.242
	D	0.625	0.545	0.040	0.233
3/4	A	0.750	0.680	0.035	0.363
	A	0.750	0.666	0.042	0.348
	D	0.750	0.666	0.042	0.348
7/8	A	0.875	0.785	0.045	0.484
	D	0.875	0.785	0.045	0.484
1 1/8	A	1.125	1.025	0.050	0.825
	D	1.125	1.025	0.050	0.825
1 3/8	A	1.375	1.265	0.055	1.26
	D	1.375	1.265	0.055	1.26

Type K Copper Pipes, Type L Copper Pipes, Type M, Medical Copper Pipe and AC Copper Pipes Chemical Compositions :

Kanchan Copper Industries produces copper pipes with ultra-purity of copper as per the international standards of composition out of safety, conductivity and the longevity of the pipes.

Copper (Cu) + Silver (Ag)	Phosphorus (P)	Alloy Designation
≥ 99.9% (combined)	0.015% – 0.040% (max)	C12200

Mechanical Properties of Copper Pipes:

Copper Pipes range manufactured by Kanchan Copper Industries are of superior tensile strength, elongation and hardness and hence suitable in pressure and non-pressure applications area. Such mechanical characteristics guarantee its decent operation in challenging installations in Maldives.

Property	Type K / L / M(ASTM B88)	Medical Copper Pipe(ASTM B819)	ACR Copper Pipe(ASTM B280)
Tensile Strength (min)	210 MPa (Hard) 205 MPa (Annealed)	210 MPa (H58 Temper – Hard)	210 MPa (H58) / 205 MPa (O60)
Yield Strength (min)	69 MPa (Hard) 45 MPa (Annealed)	69 MPa (H58 – Hard)	69 MPa (H58) / 45 MPa (O60)
Elongation (min %)	30% (Annealed) 10% (Hard)	10% (H58 – Hard)	10% (H58), 30% (O60)
Hardness (HR15T)	60–75 (Hard) 45–60 (Annealed)	60–75 (H58 – Hard)	60–75 (H58), 45–60 (O60)

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe Advantages:

Kanchan Copper Industries Copper Pipes are long-lasting, safe and durable solution to diverse piping applications in Maldives. They are an eco-friendly and cost-effective option since they are highly conductive, corrosion-resistant and recyclable. Kanchan Copper Industries advertises uniformity in the excellence of all variants, which boosts the whole performance of the plumbing systems, HVAC systems and also the medical systems.

• Corrosion Resistant: Grows well in humid places and in coastal climate such as Maldives.
• Long Lifespan: Necessitates little up-keep thus cutting down on its long run expenses.
• Fire Resister: Not combustible or combustion supportive and it improves the safety of buildings.
• Bacteria Resistant: Natural antibacterial to provide clean drinking water.
• Leak-Free Joints: Provides robust connections with it either being brazed connections or compression connections.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe Applications:

Kanchan Copper Industries have been a producer of copper Pipes that are mainly utilized in Maldives in the fixing of HVAC systems, residential plumbing, refrigeration, medical gas piping as well as the industrial transportation of fluids. They are very durable and good conductors of heat thus they make a good option in commercial infrastructures as well as in residential products.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe Industrial Applications:

• HVAC Systems
  Kanchan Copper Industries manages to deliver Copper Pipes which are good in thermal performance as far as high performance HVAC systems are concerned in Maldives hotels and resorts. They can be applied in Chilled water as well as refrigerant lines.
• Medical Gas Pipeline System (MGS)
  Provision of oxygen and vacuum gas supply within the hospitals and clinics of Maldives is made possible through Medical Grade Copper Pipes manufactured by Kanchan Copper Industries. These pipes are of international quality in terms of cleanliness and purity that can be used in the medical field.
• Refrigeration Systems
  The Kanchan Copper Industries produce AC Copper Pipes that are suitable in industrial refrigeration equipment applicable in storage and transport of foods. They operate efficiently and thus are energy efficient since they have smooth bore and can resist pressure.
• Water Treatment Plants and Desalinization
  There is corrosion resistance and strength of Copper Pipes in the desalination stations that are present all over Maldives. KCI is an entity trying to aid marine infrastructure by provisioning quality pipes.
• Fire Protecting Systems
  Copper Pipes manufactured by Kanchan Copper Industries are provided in the fire sprinkler and suppression systems laid in the commercial and public buildings because of their flame resistance and long life span.

Type K Copper Pipe, Type L Copper Pipe, Type M Copper Pipe, Medical Copper Pipe And AC Copper Pipe General Applications:

• Residential Plumbing
  Kanchan Copper Industries offers Copper Pipes which are applied in house plumbing arrangement to supply clean water in the hall. These pipes are installed easily without any dangerous fumes and they are durable to use even in apartments and homes building that are more than one-storied within Maldives.
• Air Conditionings Units
  Split AC and centralized cooling systems installed in homes and offices are made of Copper Pipes of Kanchan Copper Industries, as their leak-free connection and refrigerant flow is there in homes and offices.
• Solar water heating Systems
  Installation of solar all over Maldives relies on the use of copper to insure better transfer of heat and corrosion resistant nature. One of the products obtained at Kanchan Copper Industries is the high-temperature pipes.
• Hot and Cold Water supply
  Kanchan Copper Industries is the manufacturer of Copper Pipes that fit hot and cold water systems, which makes them an ideal product at the places of bathrooms, kitchens, and places of utility.
• Construction Projects
  The Copper Pipes produced by Kanchan Copper industries are the long term infrastructure solution used by the builders and contractors in the hotels, resorts and housing real estate of Maldives.
