Copper Buttweld Fittings Manufacturer & Exporter in Oman
Copper Buttweld Fittings are precision-made pipe fittings designed for joining, redirecting, reducing and terminating copper piping systems. They ensure secure connections and keep the flow of fluid in the pipes smooth.
As Copper Buttweld Fittings Manufacturer & Exporter in Oman, we are supplying Copper Buttweld Elbow, Tee, Coupling, Reducer, End Cap, Stub End, U Bend and Y bend for various piping needs. Our copper fittings can be used in HVAC, refrigeration, plumbing, medical gas, industrial or commercial pipes.
Kanchan Copper supply Copper Buttweld Fittings in Oman in various sizes, wall thickness, configuration and specifications as per project requirements. Our attention is paid to dimensional precision, stable production, surface quality and connection performance.
Copper Buttweld Fittings
Copper Buttweld Fittings are used to join copper pipes using butt welds. These fittings may be brazed (or joined) with an appropriate copper brazing or joining technique, depending on the application and system requirements.
Copper fittings can be used in a variety of piping systems due to their ability to conduct heat, resist corrosion, and last for a long time. Copper fittings can also offer efficient flow of fluid and gas due to their smooth inside surface.
Copper Buttweld Fittings are supplied here in Oman for contractors, distributors, engineering companies, HVAC companies, plumbing suppliers and industrial projects that need reliable Copper Pipes components.
Copper Buttweld Fittings Types
Kanchan Copper have a variety of Copper Buttweld Fittings available that are used for various piping arrangements such as changing the direction of pipe, adding branch connections, pipe size changes, and closure of pipe ends.
Copper Buttweld Elbows Fittings
Copper Buttweld Elbows are employed in order to change the direction of copper piping systems. These come in a variety of setups and angles to fit the needs of the piping system.
Elbows are used to route copper pipes at 45° and 90° in HVAC, refrigeration, plumbing and industrial applications. They offer efficient directional transition, correct pipe alignment.
Copper Buttweld Tees Fittings
Copper Buttweld Tees are used to make a common connection to a primary copper pipe. They can be found in equal and reducing configurations, depending on the arrangement of pipes needed.
Copper tees are typically installed in situations where a pipeline must branch off or divide into a second one.
Copper Buttweld Coupling Fittings
Copper Buttweld Couplings can be used to join two lengths of copper pipe in a straight run. They can be used to connect two compatible pipe sections or to extend pipe runs.
Their small size makes them ideal for a range of copper pipe work projects that need to be connected straight on.
Copper Buttweld End Caps Fittings
The Copper Buttweld End Cap is a closure that is used to cap or end a copper pipe. They are used for an appropriate closure of unused or terminated piping.
Maintenance, piping alterations, system extensions and new installations can be performed with copper end caps.
Copper Buttweld Reducers Fittings
Copper Buttweld Reducers are for joining copper pipes of different outside diameters. In a piping system they can be used to bridge the gap between smaller and larger pipe.
Reducers can be used if a pipeline needs to be reduced in size, but still needs to be compact and properly aligned.
Copper Buttweld Stub Ends Fittings
Copper Buttweld Stub Ends are applicable in pipe systems where a flanged connection is needed. They offer end connection that can be used for connecting to a compatible flange arrangement.
Stub ends can be helpful in piping systems where it is necessary to remove, inspect, maintain, or replace a section of pipe.
Copper U Bend Buttweld Fittings
Copper U Bend Buttweld Fittings are U shaped fittings that are used to create a return bend in a copper piping system.
They can be utilized when the piping configuration demands a short return route or a particular routing pattern. U bends are suitable for HVAC, refrigeration, heat-transfer and any other specialized copper piping application.
Copper Y Bend Buttweld Fittings
Copper Y Bend Buttweld Fittings are used for pipes that need to be configured in a Y shape in particular applications.
They can be produced to meet specific project needs and dimensions for specific industrial and copper piping applications.
Copper Buttweld Fittings Specification
The Copper Buttweld Fittings can be produced and delivered in varied dimensions, wall thickness, material and configuration, depending on the fitting type, based on the application needs. The material grade, size, wall thickness and applicable standard can be selected based on the piping system and customer needs.
| Standard | ASTM B819, EN 1057, EN 13348, ASTM B88 |
|---|---|
| Size | 1/2″ to 24″ NB |
| Thickness | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
| Type | Welded |
| Schedule | SCH 10, SCH 20, SCH 30, SCH 40 |
| Grades | DHP Copper, C10100, C10200, C11000, C12000, C12200 |
| Application | HVAC & Refrigeration, Plumbing, Industrial Piping, Heat Exchangers, Cooling Systems, Engineering Applications |
Copper Buttweld Fittings Pressure Rating Schedule Chart
| NPS (Normal Size Of Steel Pipe) | 10S Sche | 40S Sche | 80S Sche | ||||||
|---|---|---|---|---|---|---|---|---|---|
| 90 Deg Elbow | 45 Deg Elbow | Equal Tee | 90 Deg Elbows | 45 Deg Elbows | Equal Tee | 90 Deg Elbow | 45 Deg Elbow | Equal Tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.1 | 0.1 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.2 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.4 | 0.23 | 0.68 |
| 40 | 0.3 | 0.17 | 0.68 | 0.4 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.5 | 0.25 | 0.85 | 0.7 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.4 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.2 | 1.08 | 3.31 | 2.97 | 1.5 | 4.45 |
| 90 | 1.7 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4 | 2 | 5.44 |
| 100 | 2.1 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.2 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.9 |
| 300 | 25.8 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Copper Elbow Buttweld Fittings size, dimension chart
| NPS For (Normal Size Of Pipe) | O.D. For (Outside Dai.) | BW 90 Deg Elbow | BW 45 Deg Elbow | BW Return 180 Deg Elbow | ||||
|---|---|---|---|---|---|---|---|---|
| BW (Long Radius) Elbow | BW (Short Radius) Elbow | BW (Long Radius) Elbow | BW (Short Radius) Elbow | |||||
| (In Inch) | (MM) | (inch) | Center-Face (Inches) | Center-Face (Inches) | Center-Face (In Inches) | Radius (In Inches) | Center-Center (In Inches) | Back-face (In Inches) |
| 1/2 | 21.3 | 0.84 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.05 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.66 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.9 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.5 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.5 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.75 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
Copper Buttweld Fittings Tolerance
| Common Type Of Buttweld Fitting | 45 degree elbows And 90 deg elbows | 180 Deg Returns | |||||
|---|---|---|---|---|---|---|---|
| Normal Size Of Steel Pipe | O.D. at Bevel | I.D. at End | WT For (Wall Thickness) t / t1 | Center-End Dai. A-B-C-M | Center-Center Dai. (O) | Back-Face Dai. (K) | Align-ment of Ends (U) |
| 1/2 a 2 1/2 | 1 | 0,8 | Not | 2 | 7 | 7 | 1 |
| 3 a 3 1/2 | 1 | 1,6 | less | 2 | 7 | 7 | 1 |
| 4 | 1 | 1,6 | than | 2 | 7 | 7 | 1 |
| 5 a 6 | 2 | 1,6 | 87,50% | 2 | 7 | 7 | 1 |
| 8 | 2 | 1,6 | of nominal | 2 | 7 | 7 | 1 |
| 10 | 1 | 3,2 | tickness | 2 | 7 | 7 | 2 |
| 12 a 18 | 1 | 3,2 | 3 | 10 | 7 | 2 | |
| 20 a 24 | 1 | 4,8 | 3 | 10 | 7 | 2 | |
| 26 a 30 | 2 | 4,8 | 3 | – | – | – | – |
| 32 a 48 | 2 | 4,8 | 5 | – | – | – | – |
Applications of Copper Buttweld Fittings
Copper Buttweld Fittings are used in various building services and industries where copper piping systems are needed.
- HVAC Systems
Copper elbows, tees, couplings, reducers and other fittings are used to route and connect copper pipe in heating, ventilation and air-conditioning systems. - Refrigeration Systems
In refrigeration piping copper fittings are commonly used to make connections and flow routes for refrigerant piping. They can be used in different refrigeration installations due to their thermal properties and compatibility with copper piping. - Plumbing Systems
- Copper Buttweld Fittings can be used in hot and cold water plumbing systems. With the right selection of material and installation, copper offers good durability and corrosion resistance.
- Medical Gas Pipeline Systems
When manufactured and installed to comply with the applicable medical-gas requirements, suitable copper piping components are suitable for use in medical-gas pipeline systems for oxygen, medical air, vacuum and other medical-gas applications. - Industrial Piping
Copper used in selected industrial applications for fluid, gas, heat-transfer and specialized copper piping systems. - Heat Transfer Systems
Copper piping and fittings are appropriate for use in applications where efficient heat transfer is needed due to copper’s high thermal conductivity. - Commercial Buildings
Copper Buttweld Fittings may be applied in a variety of mechanical and other piping applications, HVAC, refrigeration and plumbing systems in commercial buildings.
