Copper Buttweld Fittings Manufacturer & Exporter in Israel
Copper Buttweld Fittings are precision-engineered pipe fittings that can be used to connect, redirect, reduce or terminate a copper plumbing system. These fittings ensure secure connections and smooth flow, offering reliable operation within the piping system.
Kanchan Copper are Copper Buttweld Fittings Manufacturer & Exporter in Israel, and provide Copper Buttweld Elbows, Tees, Couplings, Reducers, End Caps, Stub Ends, U Bends and Y Bends for various piping needs. Our copper fittings are ideal for HVAC/Refrigeration, plumbing, medical gas, industrial and commercial piping.
The Copper Buttweld Fittings in Israel come in various sizes, wall thicknesses, shapes, and specifications, catering to the requirements of the project. We assure you on dimensional precision, regular production, surface finishing and connection performance.
Copper Buttweld Fittings
Buttweld Fittings are used in a butt connection with copper pipe. These fittings may be joined by appropriate copper brazing and joining techniques to suit the application and system requirements. Kanchan Copper are a supplier of Copper Buttweld Fittings in Israel for contractors, distributors, engineering and HVAC companies, plumbing suppliers and industrial projects that need reliable copper pipe fittings.
Copper Buttweld Fittings Types
Kanchan Copper have various Copper Buttweld Fittings for various piping configurations such as changes in direction, branch connections, pipe-size transitions and pipe-end closures.
Copper Buttweld Elbows Fittings
Copper Buttweld Elbows are fabricated to alter the direction of copper pipe. These come in a variety of configurations and bend angles, depending on the needs of the piping layout.
The 45° and 90° copper elbows are utilized for the purpose of making turns in copper pipes, which are a common feature in HVAC, refrigeration, plumbing, and industrial systems.
Copper Buttweld Tees Fittings
Copper Buttweld Tees are used to make a branch connection from a copper main. They can be used in either equal or reducing configuration depending on the pipe arrangement desired.
The copper tee is typically used when a pipe has to split or connect with another pipe.
Copper Buttweld Coupling Fittings
Copper Buttweld Couplings are used to join copper pipes in straight line configuration. These can be employed on two compatible pipe sections or on an extension of pipes.
Their small size makes them useful in a number of circumstances using copper piping where a straight connection is needed.
Copper Buttweld End Caps Fittings
Copper Buttweld End Caps are used to cap or terminate the end of a copper pipe. They can be used to close off unused or terminated sections of piping systems.
Copper end caps can be utilized for new installations, piping changes, maintenance, and extension of systems.
Copper Buttweld Reducers Fittings
Copper Buttweld Reducers are used to join copper pipes together that have different outside diameters. They are used to connect one pipe to another in a piping system that has to change size.
Reducers are helpful for situations where size variations are necessary within the same pipeline and a small and aligned connection is desired.
Copper Buttweld Stub Ends Fittings
Copper Buttweld Stub Ends are stub ends with a flanged end connection, used in piping applications that require a flanged connection. They offer an end connection that can be used with a mating flange arrangement.
Stub ends may be helpful when sections of piping are needed for easier removal, inspection, maintenance or replacement.
Copper U Bend Buttweld Fittings
These Copper U Bend Buttweld Fittings are made in a U shape to create a U bend in a copper piping system.
They can be used when routing of pipes needs to be done in a special way or a compact return path. U bends are applicable for HVAC, refrigeration, heat-transfer and other special copper piping applications.
Copper Y Bend Buttweld Fittings
Copper Y Bend Buttweld Fittings are provided for special applications where a Y-shaped piping configuration is required.
They can be produced to desired sizes and project specifications for chosen industrial and copper piping applications.
Copper Buttweld Fittings Specification
Based on the type of fitting and application requirements, Copper Buttweld Fittings can be manufactured and supplied in various sizes, wall thickness, materials and configurations. The specific material, size, wall thickness and standard can be chosen based on your system and your needs.
| Standard | ASTM B819, EN 1057, EN 13348, ASTM B88 |
|---|---|
| Size | 1/2″ to 24″ NB |
| Thickness | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
| Type | Welded |
| Schedule | SCH 10, SCH 20, SCH 30, SCH 40 |
| Grades | DHP Copper, C10100, C10200, C11000, C12000, C12200 |
| Application | HVAC & Refrigeration, Plumbing, Industrial Piping, Heat Exchangers, Cooling Systems, Engineering Applications |
Copper Buttweld Fittings Pressure Rating Schedule Chart
| NPS (Normal Size Of Steel Pipe) | 10S Sche | 40S Sche | 80S Sche | ||||||
|---|---|---|---|---|---|---|---|---|---|
| 90 Deg Elbow | 45 Deg Elbow | Equal Tee | 90 Deg Elbows | 45 Deg Elbows | Equal Tee | 90 Deg Elbow | 45 Deg Elbow | Equal Tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.1 | 0.1 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.2 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.4 | 0.23 | 0.68 |
| 40 | 0.3 | 0.17 | 0.68 | 0.4 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.5 | 0.25 | 0.85 | 0.7 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.4 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.2 | 1.08 | 3.31 | 2.97 | 1.5 | 4.45 |
| 90 | 1.7 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4 | 2 | 5.44 |
| 100 | 2.1 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.2 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.9 |
| 300 | 25.8 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Copper Elbow Buttweld Fittings size, dimension chart
| NPS For (Normal Size Of Pipe) | O.D. For (Outside Dai.) | BW 90 Deg Elbow | BW 45 Deg Elbow | BW Return 180 Deg Elbow | ||||
|---|---|---|---|---|---|---|---|---|
| BW (Long Radius) Elbow | BW (Short Radius) Elbow | BW (Long Radius) Elbow | BW (Short Radius) Elbow | |||||
| (In Inch) | (MM) | (inch) | Center-Face (Inches) | Center-Face (Inches) | Center-Face (In Inches) | Radius (In Inches) | Center-Center (In Inches) | Back-face (In Inches) |
| 1/2 | 21.3 | 0.84 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.05 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.66 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.9 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.5 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.5 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.75 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
Copper Buttweld Fittings Tolerance
| Common Type Of Buttweld Fitting | 45 degree elbows And 90 deg elbows | 180 Deg Returns | |||||
|---|---|---|---|---|---|---|---|
| Normal Size Of Steel Pipe | O.D. at Bevel | I.D. at End | WT For (Wall Thickness) t / t1 | Center-End Dai. A-B-C-M | Center-Center Dai. (O) | Back-Face Dai. (K) | Align-ment of Ends (U) |
| 1/2 a 2 1/2 | 1 | 0,8 | Not | 2 | 7 | 7 | 1 |
| 3 a 3 1/2 | 1 | 1,6 | less | 2 | 7 | 7 | 1 |
| 4 | 1 | 1,6 | than | 2 | 7 | 7 | 1 |
| 5 a 6 | 2 | 1,6 | 87,50% | 2 | 7 | 7 | 1 |
| 8 | 2 | 1,6 | of nominal | 2 | 7 | 7 | 1 |
| 10 | 1 | 3,2 | tickness | 2 | 7 | 7 | 2 |
| 12 a 18 | 1 | 3,2 | 3 | 10 | 7 | 2 | |
| 20 a 24 | 1 | 4,8 | 3 | 10 | 7 | 2 | |
| 26 a 30 | 2 | 4,8 | 3 | – | – | – | – |
| 32 a 48 | 2 | 4,8 | 5 | – | – | – | – |
Applications of Copper Buttweld Fittings
Copper Buttweld Fittings find use in a wide variety of building services and industries wherever copper piping is necessary.
- HVAC Systems
The routing and connecting of copper pipe in heating, ventilation and air-conditioning systems is accomplished using copper elbows, tees, couplers, reducers and other fittings. - Refrigeration Systems
Copper fittings are commonly used for the refrigerant lines in refrigeration systems to connect and route the refrigerant flow. They can be used in a variety of refrigeration applications due to their thermal characteristics and compatibility with copper pipe. - Plumbing Systems
Copper Buttweld Fittings can be used in hot and cold water plumbing systems. Copper can offer excellent corrosion resistance and durability if the copper and installing technique are correctly chosen. - Medical Gas Pipeline Systems
Medical gas pipeline systems that meet the appropriate medical-gas requirements and utilize suitable copper piping components are acceptable for use with oxygen, medical air, vacuum and other medical gas applications. - Industrial Piping
Copper fittings are employed in certain industrial applications such as fluid, gas, heat-transfer and special copper piping systems. - Heat Transfer Systems
The high thermal conductivity of copper allows copper piping and fittings to be used in applications where effective transfer of heat is essential. - Commercial Buildings
Copper Buttweld Fittings are applicable in commercial building services, such as HVAC systems, refrigeration, plumbing and mechanical piping.
