Copper Buttweld Fittings Manufacturer & Exporter in Dubai
Copper Buttweld Fittings are precision manufactured pipe fittings that are used to join, redirect, reduce or terminate a copper pipe system. These fittings ensure secure connections and a smooth flow through the pipes.
As a Copper Buttweld Fittings Manufacturer & Exporter in Dubai, we supply a wide range of Copper Buttweld Elbows, Tees, Couplings, Reducers, End Caps, Stub Ends, U Bends, Y Bends for various piping needs. Our copper fittings can be used in HVAC, refrigeration, plumbing, medical gas, industrial and commercial pipe.
Kanchan Copper Buttweld Fittings Dubai come in various sizes, wall thickness, configurations and specification that are available to suit the needs of a project. Our emphasis is on dimensional precision, uniform production, correct surface finish and connection performance.
Copper Buttweld Fittings
Copper Buttweld Fittings are used for butt welding with copper pipes. These fittings can be brazed and joined by appropriate copper brazing and joining techniques, depending on the application and system requirements.
Copper has a superior thermal conduction, corrosion resistance and durability, so copper fittings have a wide application in various piping systems. Copper fittings can also offer efficient flow of fluids and gases due to their smooth inner surface.
Contractors, distributors, engineering firms, HVAC companies, plumbing suppliers and industrial projects needing reliable copper piping components can rely on us to supply Copper Buttweld Fittings in Dubai.
Copper Buttweld Fittings Types
Kanchan Copper have a variety of Copper Buttweld Fittings available for various piping situations such as change of direction, branches, change in pipe size and pipe end closures.
Copper Buttweld Elbows Fittings
Copper Buttweld Elbows are employed for direction changes in copper pipe. They come in various configurations and have different bend angles to suit the needs of the piping layout.
Copper elbows with 45° and 90° bends are typically used for routing copper pipes in all HVAC, refrigeration, plumbing and industrial applications. They offer a quick, easy and efficient directional change and also ensure the correct alignment of pipe.
Copper Buttweld Tees Fittings
Copper Buttweld Tees are required to make the connection of a branch line from the main copper line. They can be equal and reducing depending on the type of pipe arrangement needed.
A copper tee is generally utilized when a pipeline system requires that it be split or a lateral be added to it.
Copper Buttweld Coupling Fittings
Copper Buttweld Couplings are used to connect two copper pipes together in straight line. They can be used to extend pipe lines or connect two pipe lines that are not compatible.
Their small size allows them to be used in a variety of copper pipe applications that require a straight connection.
Copper Buttweld End Caps Fittings
The copper buttweld end cap is used to cap the end of a copper pipe. They serve as an appropriate end point for un-used and terminated pipelines.
Copper end caps are suitable for new installations, pipe modifications, maintenance and system extensions.
Copper Buttweld Reducers Fittings
Copper Buttweld Reducers are used to connect copper pipes with different outside diameters. They are used in a piping system to connect two different pipe sizes together.
Reducers are employed when a change in the size of the pipe-line is necessary, but a compact and properly aligned connection is desired.
Copper Buttweld Stub Ends Fittings
Copper Buttweld Stub Ends are applied in a piping system where a flanged connection is desired. They offer an end connection that can be adapted to a compatible flange set up.
Stub ends are beneficial for systems that need to have pipe sections removed, inspected, maintained, or replaced.
Copper U Bend Buttweld Fittings
The Copper U Bend Buttweld Fittings are formed into U-shape to create a ‘U’ bend within copper piping.
They are handy for situations in which the layout of the piping calls for a short return or special routing. U bends are used in HVAC, refrigeration, heat-transfer and other specialized copper piping applications.
Copper Y Bend Buttweld Fittings
Copper Y Bend Buttweld Fittings are manufactured for unique piping systems that require a Y-shaped fitting.
They can be produced as per project needs and dimensions for the selected copper and industrial piping.
Copper Buttweld Fittings Specification
Copper Buttweld Fittings can be produced and supplied in various sizes, wall thickness, material and forms depending on the fitting type and application needs. Material grade, size, wall thickness, and standard can be specified based on the piping system and customer requirements.
| Standard | ASTM B819, EN 1057, EN 13348, ASTM B88 |
|---|---|
| Size | 1/2″ to 24″ NB |
| Thickness | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
| Type | Welded |
| Schedule | SCH 10, SCH 20, SCH 30, SCH 40 |
| Grades | DHP Copper, C10100, C10200, C11000, C12000, C12200 |
| Application | HVAC & Refrigeration, Plumbing, Industrial Piping, Heat Exchangers, Cooling Systems, Engineering Applications |
Copper Buttweld Fittings Pressure Rating Schedule Chart
| NPS (Normal Size Of Steel Pipe) | 10S Sche | 40S Sche | 80S Sche | ||||||
|---|---|---|---|---|---|---|---|---|---|
| 90 Deg Elbow | 45 Deg Elbow | Equal Tee | 90 Deg Elbows | 45 Deg Elbows | Equal Tee | 90 Deg Elbow | 45 Deg Elbow | Equal Tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.1 | 0.1 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.2 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.4 | 0.23 | 0.68 |
| 40 | 0.3 | 0.17 | 0.68 | 0.4 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.5 | 0.25 | 0.85 | 0.7 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.4 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.2 | 1.08 | 3.31 | 2.97 | 1.5 | 4.45 |
| 90 | 1.7 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4 | 2 | 5.44 |
| 100 | 2.1 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.2 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.9 |
| 300 | 25.8 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Copper Elbow Buttweld Fittings size, dimension chart
| NPS For (Normal Size Of Pipe) | O.D. For (Outside Dai.) | BW 90 Deg Elbow | BW 45 Deg Elbow | BW Return 180 Deg Elbow | ||||
|---|---|---|---|---|---|---|---|---|
| BW (Long Radius) Elbow | BW (Short Radius) Elbow | BW (Long Radius) Elbow | BW (Short Radius) Elbow | |||||
| (In Inch) | (MM) | (inch) | Center-Face (Inches) | Center-Face (Inches) | Center-Face (In Inches) | Radius (In Inches) | Center-Center (In Inches) | Back-face (In Inches) |
| 1/2 | 21.3 | 0.84 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.05 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.66 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.9 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.5 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.5 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.75 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
Copper Buttweld Fittings Tolerance
| Common Type Of Buttweld Fitting | 45 degree elbows And 90 deg elbows | 180 Deg Returns | |||||
|---|---|---|---|---|---|---|---|
| Normal Size Of Steel Pipe | O.D. at Bevel | I.D. at End | WT For (Wall Thickness) t / t1 | Center-End Dai. A-B-C-M | Center-Center Dai. (O) | Back-Face Dai. (K) | Align-ment of Ends (U) |
| 1/2 a 2 1/2 | 1 | 0,8 | Not | 2 | 7 | 7 | 1 |
| 3 a 3 1/2 | 1 | 1,6 | less | 2 | 7 | 7 | 1 |
| 4 | 1 | 1,6 | than | 2 | 7 | 7 | 1 |
| 5 a 6 | 2 | 1,6 | 87,50% | 2 | 7 | 7 | 1 |
| 8 | 2 | 1,6 | of nominal | 2 | 7 | 7 | 1 |
| 10 | 1 | 3,2 | tickness | 2 | 7 | 7 | 2 |
| 12 a 18 | 1 | 3,2 | 3 | 10 | 7 | 2 | |
| 20 a 24 | 1 | 4,8 | 3 | 10 | 7 | 2 | |
| 26 a 30 | 2 | 4,8 | 3 | – | – | – | – |
| 32 a 48 | 2 | 4,8 | 5 | – | – | – | – |
Applications of Copper Buttweld Fittings
Copper Buttweld Fittings are applied in various sectors and building services where copper pipe is required.
- HVAC Systems
Copper elbows, tees, couplings, reducers and other fittings may be used to route and connect copper pipe in heating, ventilation and air-conditioning applications. - Refrigeration Systems
Copper fittings are commonly utilized in refrigerant lines for connecting and routing of refrigerant lines in refrigeration systems. They have thermal properties and compatibility with copper piping and can be used in other refrigeration installations. - Plumbing Systems
Copper Buttweld Fittings can be used in hot and cold water plumbing systems. Copper exhibits good resistance and durability, provided it is chosen carefully along with the appropriate installation technique. - Medical Gas Pipeline Systems
Medical-gas pipeline systems, including oxygen, medical air, vacuum and other medical gas applications, can be constructed of suitable copper pipe components, manufactured and installed to meet applicable medical-gas requirements. - Industrial Piping
Copper fittings are used in specialized copper piping, heat-transfer, fluid and gas applications. - Heat Transfer Systems
The high thermal conductivity of copper is ideal for use in applications where heat transfer is important, such as copper piping and fittings. - Commercial Buildings
Copper Buttweld Fittings are suitable for commercial building service applications such as HVAC systems, refrigeration systems, plumbing systems and mechanical piping systems.
