Copper Buttweld Fittings Manufacturer & Exporter in Abu Dhabi
Copper Buttweld Fittings are precision manufactured pipe fittings that can be utilized to join, redirect, reduce or terminate copper pipes. They give consistent connections and are smooth in the lines.
We are Copper Buttweld Fittings manufacturer & exporter in Abu Dhabi with Copper Buttweld Elbows, Tees, Couplings, Reducers, End Caps, Stub Ends, U Bends and Y Bends for various piping needs. Our copper fittings can be used in HVAC, refrigeration, plumbing, medical gas, industrial and commercial piping systems.
Our Copper Buttweld Fittings in Abu Dhabi come in a variety of sizes, wall thicknesses, configurations and specifications to suit project requirements. Dimensional accuracy, consistency of manufacturing, appropriate surface finish, and connection performance are our priorities.
Copper Buttweld Fittings
Copper Buttweld Fittings are used to make a butt joint with copper pipe. These fittings may be brazed and joined to copper by appropriate copper brazing and joining techniques, depending on the use and system needs. Copper Buttweld Fittings in Abu Dhabi are available for contractors, distributors, engineering companies, HVAC companies, plumbing suppliers, and industrial projects that require reliable copper pipe fittings.
Copper Buttweld Fittings Types
We have a variety of Copper Buttweld Fittings available to meet the needs of various piping configurations, such as directional changes, branch connections, changes in pipe size and end closures.
Copper Buttweld Elbows Fittings
Copper Buttweld Elbows are used to change the direction of copper piping systems. They are available in different configurations and bend angles according to the requirements of the piping layout.
Copper elbows are frequently employed for routing copper pipes in HVAC, refrigeration, plumbing, and industrial applications, with the most popular models being 45° and 90°. They offer a smooth directional change and correct pipe alignment.
Copper Buttweld Tees Fittings
Copper Buttweld Tees are used for making a lateral connection to a trunk copper pipe. They can be configured in equal or reducing mode, depending on the desired pipe configuration.
Copper tees are typically found in situations that require a branch connection to another pipeline, or a division in a piping system.
Copper Buttweld Coupling Fittings
Copper Buttweld Couplings are used to join two copper pipes end to end. They can be used to make longer runs of piping or to connect two compatible pipe sections.
They are compact and can be used in different types of copper pipe installations where a straight connection is to be made.
Copper Buttweld End Caps Fittings
Copper Buttweld End Caps are designed to cap or end a copper pipe. They are designed to properly seal abandoned or discarded sections of piping.
Copper end caps are suitable for new installations, pipe changes, maintenance and piping extensions.
Copper Buttweld Reducers Fittings
Copper Buttweld Reducers are used to join pipes made of copper of varying outside diameters. They are used to connect different pipe sizes in a piping system.
Reducers are helpful when a pipeline diameter needs to be reduced without having to separate the pipe or make the connection misaligned.
Copper Buttweld Stub Ends Fittings
Copper Buttweld Stub Ends are applied in pipe configurations where a flanged configuration is necessary. They have an end connection that would make it compatible with a compatible flange arrangement.
Stub ends are helpful in systems where it is desirable to remove, inspect, maintain or replace sections of piping.
Copper U Bend Buttweld Fittings
Copper U Bend Buttweld Fittings are a type of fitting that features a U-shaped bend and is used to make a return bend in a copper piping system.
They can be helpful when the return path of the piping requires particular routing or a tight space. U bends may be used in HVAC, refrigeration, heat-transfer and other special applications for copper pipe.
Copper Y Bend Buttweld Fittings
Copper Y Bend Buttweld Fittings are specifically created for pipe setups that require a Y-shaped bend.
They can be fabricated to desired sizes and project needs for specific industrial and copper piping projects.
Copper Buttweld Fittings Specification
The Copper Buttweld Fittings can be produced and provided in various type of sizes, wall thickness, metal, and shapes, based on the type of the fitting and the application. The actual Material Grade, Dimension, Wall thickness, Standard can be selected as per the piping system and customer requirement.
| Standard | ASTM B819, EN 1057, EN 13348, ASTM B88 |
|---|---|
| Size | 1/2″ to 24″ NB |
| Thickness | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
| Type | Welded |
| Schedule | SCH 10, SCH 20, SCH 30, SCH 40 |
| Grades | DHP Copper, C10100, C10200, C11000, C12000, C12200 |
| Application | HVAC & Refrigeration, Plumbing, Industrial Piping, Heat Exchangers, Cooling Systems, Engineering Applications |
Copper Buttweld Fittings Pressure Rating Schedule Chart
| NPS (Normal Size Of Steel Pipe) | 10S Sche | 40S Sche | 80S Sche | ||||||
|---|---|---|---|---|---|---|---|---|---|
| 90 Deg Elbow | 45 Deg Elbow | Equal Tee | 90 Deg Elbows | 45 Deg Elbows | Equal Tee | 90 Deg Elbow | 45 Deg Elbow | Equal Tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.1 | 0.1 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.2 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.4 | 0.23 | 0.68 |
| 40 | 0.3 | 0.17 | 0.68 | 0.4 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.5 | 0.25 | 0.85 | 0.7 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.4 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.2 | 1.08 | 3.31 | 2.97 | 1.5 | 4.45 |
| 90 | 1.7 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4 | 2 | 5.44 |
| 100 | 2.1 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.2 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.9 |
| 300 | 25.8 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Copper Elbow Buttweld Fittings size, dimension chart
| NPS For (Normal Size Of Pipe) | O.D. For (Outside Dai.) | BW 90 Deg Elbow | BW 45 Deg Elbow | BW Return 180 Deg Elbow | ||||
|---|---|---|---|---|---|---|---|---|
| BW (Long Radius) Elbow | BW (Short Radius) Elbow | BW (Long Radius) Elbow | BW (Short Radius) Elbow | |||||
| (In Inch) | (MM) | (inch) | Center-Face (Inches) | Center-Face (Inches) | Center-Face (In Inches) | Radius (In Inches) | Center-Center (In Inches) | Back-face (In Inches) |
| 1/2 | 21.3 | 0.84 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.05 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.66 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.9 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.5 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.5 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.75 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
Copper Buttweld Fittings Tolerance
| Common Type Of Buttweld Fitting | 45 degree elbows And 90 deg elbows | 180 Deg Returns | |||||
|---|---|---|---|---|---|---|---|
| Normal Size Of Steel Pipe | O.D. at Bevel | I.D. at End | WT For (Wall Thickness) t / t1 | Center-End Dai. A-B-C-M | Center-Center Dai. (O) | Back-Face Dai. (K) | Align-ment of Ends (U) |
| 1/2 a 2 1/2 | 1 | 0,8 | Not | 2 | 7 | 7 | 1 |
| 3 a 3 1/2 | 1 | 1,6 | less | 2 | 7 | 7 | 1 |
| 4 | 1 | 1,6 | than | 2 | 7 | 7 | 1 |
| 5 a 6 | 2 | 1,6 | 87,50% | 2 | 7 | 7 | 1 |
| 8 | 2 | 1,6 | of nominal | 2 | 7 | 7 | 1 |
| 10 | 1 | 3,2 | tickness | 2 | 7 | 7 | 2 |
| 12 a 18 | 1 | 3,2 | 3 | 10 | 7 | 2 | |
| 20 a 24 | 1 | 4,8 | 3 | 10 | 7 | 2 | |
| 26 a 30 | 2 | 4,8 | 3 | – | – | – | – |
| 32 a 48 | 2 | 4,8 | 5 | – | – | – | – |
Applications of Copper Buttweld Fittings
Copper Buttweld Fittings are applicable in various industries and building services where copper piping system is needed.
- HVAC Systems
Copper elbows, tees, couplers, reducer fittings, and others are used for routing and connecting copper pipe in heating, ventilation and air-conditioning systems. - Refrigeration Systems
Copper is commonly employed in refrigeration systems to connect and route refrigerant lines, as copper fittings. They are suitable to be used in various refrigeration installations due to their thermal properties and compatibility with copper piping. - Plumbing Systems
Copper Buttweld Fittings can be used in hot and cold water plumbing systems. With proper selection of materials and installation techniques, copper will be delivered with excellent corrosion resistance and durability. - Medical Gas Pipeline Systems
When manufactured and installed in compliance with the applicable medical-gas requirements, appropriate copper pipeline components may be used in medical gas pipeline systems for medical-gas applications, including oxygen, medical air, vacuum and other medical gases. - Industrial Piping
Copper fittings are utilized in certain industrial applications such as fluid services, gas services, heat-transfer services and special copper piping systems. - Heat Transfer Systems
Copper piping and fittings can be used in applications where efficient heat transfer is required due to its high thermal conductivity. - Commercial Buildings
Copper Buttweld Fittings are suitable for commercial building services such as HVAC systems, refrigeration systems, plumbing, and mechanical piping systems.
